Column Moving NC Surface Grinding Machine / Surface Grinder
- 45 Set / Sets per Month
- China Port
- T/T Credit Card
- Second-hand sweeper second-hand mobile phone curved glass sweeper tablet computer curved glass sweeper
- Automatic Ultrafine Powder Grinder with Ceramic Mortar
- Automatic Powder Grinder with Ceramic Mortar
- Pneumatically-lifted Laboratory Grinder (Special grinding equipment for scientific research in Colleges and Universities)
- Pneumatically-lifted Grinder with Double Pestle and Ceramic Mortar (manual discharging)
- Pneumatically-lifted Grinder with Ceramic Mortar (Large grinder for chemical material and new material)
Product Details
Condition: | New | Type: | Surface Grinding Machine | CNC or Not: | CNC |
Max. Grinding Diameter: | as model | Max. Grinding Length: | Effective Length | Brand Name: | TIMAC |
Model Number: | SG-50100A,SG-60125A | Voltage: | as customer's request | Power(W): | 7.5KW |
Dimension(L*W*H): | 3990mm*2250mm*2280mm | Weight: | as model | Certification: | CE & ISO |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
"SG Series" Column Moving NC Surface Grinding Machine /Surface Grinder
Features:
* Independent hydraulic unit ensures high temperature stability and with auto. central lubrication;
* Very easy to set auto. ground program include rough, finish, and spark-out stroke.
* Precision grinding spindle runs in maintenance free,suported by preload high precision angular ball bearing;
* Machine is designed for continuous operating at maximum speed, very quiet operation, maximum accuracy.
* The machine bed,table and column are high grade casting piece, which supply strong base of grinding.The slideway is coated with TF wearable material and with precision hand scrapped.
Standard Accessories:
Coolant tank, Wheel dresser base, Flange and wheel extractor, Standard wheel, Balance arbor, Balance stand, Working lamb, Leveling wedge and foundation bolt, PLC grinding controller,
Built in electro magnetic chuck controlller, 2 axes feed control electro hand wheel(MPG).
Optional Accessories:
Electro magnetic chuck, Hydraulic parallel wheel dreser, Coolant tank with magnetic separator, Coolant tank with paper filter, Coolant tank with magnetic separator and paper filter.
Parameter:
Specification | Unit | SG-50100A | SG-50160A | SG-60125A | SG-60160A | SG-60220A | |
Table size(W×L) | mm | 500×1000 | 500×1600 | 600×1250 | 600×1600 | 600×2200 | |
Max. grinding size(W×L) | mm | 500×1000 | 500×1600 | 600×1250 | 600×1600 | 600×2200 | |
Max.distance from spindle center | mm | 600 | |||||
Magnetic chuck size(Optional) | mm | 500×1000 | 500×800 | 600×1000 | 600×800 | 600×1000 | |
Speed of table longitudinal movement | mm | 5-25 | |||||
Wheelhead cross | Auto feed | mm/stroke | 1-20 | ||||
Rapid speed | mm/min | 50-1500 | |||||
Feed of electro handwheel | mm/div | 0.005 | |||||
Wheelhead vertical | Auto feed | mm/stroke | 0.005/0.01/0.02/0.03/0.04 | ||||
Rapid speed | mm/min | 50-500 | |||||
Feed of electro handwheel | mm/div | 0.002 | |||||
Grinding wheel | Speed | rpm | 1450(50HZ),1750(60HZ) | ||||
Size(O.D×W×I.D) | mm | 355×(20-50)×127 | |||||
Spindle motor | kw | 7.5 | |||||
Max. loading capacity of table | kg | 700 | 880 | 970 | 1230 | 1690 | |
Total rated power | kw | 12 | 14 | ||||
Gross weight | kg | 5500 | 6000 | 6500 | 7000 | 8000 | |
Packing dimensions(L×W×H) | cm | 399×225×228 | 564×225×228 | 472×230×228 | 560×230×228 | 600×230×228 |
