" 39~165mm Boring Dia." Motorcycle Cylinder Boring Machine T806 & T806A & T807
US$ 800 - 2,000
MOQ: 5 Sets
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Production Capacity:
High
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
"30-180mm Boring Dia." Vertical Cylinder Boring Machine T-8018A & T-8018B & T-8018CUS$ 7,962 - 10,417MOQ: 1 Set -
"160mm Boring Dia." Vertical Boring Machine T716AUS$ 3,500 - 15,980MOQ: 1 Set
-
"200mm Boring Dia." Vertical Boring Machine T7220BUS$ 3,500 - 15,980MOQ: 1 Set
-
"200mm Boring Dia." Vertical Boring Machine T7220CUS$ 3,500 - 15,980MOQ: 1 Set
-
Vertical Cylinder Honing Machine THM170US$ 5,000 - 13,000MOQ: 1 Set
Condition
New
CNC or Not
Normal
Production Capacity
High
Brand Name
TIMAC
Model Number
T806 & T806A & T807 & T8018A
Voltage
220V/380V
Power(W)
0.25kw
Dimension(L*W*H)
350x272x725 Mm
Weight
80KG
Certification
ISO
Motorcycle Cylinder Boring Machine
Feature:
Motorcycle Cylinder Boring Machine
1. The machine is mainly used for reboring engine cylinders of automobiles motor cycles and tractors.
2. Reliable performance, widely use, processing accuracy high productivity.
3. Easy and flexible operation.
Parameter:
| Model | T806 | T807 | T806A | T808A | T8014A | T8016A | |
| Boring diameter | Φ39-Φ60 mm | Φ39-Φ70 mm | Φ46-Φ80 mm | Φ50-Φ85 mm | Φ65-Φ140 mm | Φ80-Φ165 mm | |
| Max. boring depth | 160 mm | 160 mm | 160 mm | 170 mm | 300 mm | 400 mm | |
| Spindle speed | 486 r/min | 486 r/min | 486 r/min | 394 r/min | 250;380 r/min | 200;300 r/min | |
| Spindle feed | 0.09 mm / r | 0.09 mm / r | 0.09 mm / r | 0.10 mm / r | 0.11 mm / r | 0.12 mm / r | |
| Spindle rapid reset | 636 mm / min | 780 mm / min | |||||
| Motor | Voltage | 220/380 V | 220/380 V | 220/380 V | 220/380 V | 220/380 V | 220/380 V |
| Power | 0.25 Kw | 0.25 Kw | 0.25 Kw | 0.25 Kw | 0.25/0.37 Kw | 0.25/0.37 Kw | |
| Speed | 1440 r/min | 1440 r/min | 1440 r/min | 1440 r/min | 1440 r/min | 1440 r/min | |
| Overall dimensions |
330×400× 1080 mm |
330×400× 1080 mm |
330×400× 1080 mm |
350×272× 725 mm |
320×330× 850 mm |
360×345× 1100 mm |
|
| Packing dimensions | 490×520×1290 mm | 490×520×1290 mm | 490×520×1290 mm | 460×440×870 mm | 540×470×1030 mm | 500×490×1270 mm | |
| Weight | 80 Kg | 80 Kg | 80 Kg | 48 Kg | 62 Kg | 85 Kg | |
OEM Program: Brand & Logo, Color & Vlotage can be appointed by you.
Delivery time: 60days or so.
Packing : In wooden cases (Can be fumigated )
Payment terms: T/T with 30% down payment.
Warranty period: 1 year after delivery.
Spares & Technology Support Services
Choose "TIMEWAY MACHINE" is your right choice !!!
