Brake Drum Lathe/Disc Cutting Machine

Name: Brake Drum Lathe/Disc Cutting Machine
Brand: TIMAC
SKU: 140797118
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

Brake Drum Lathe/Disc Cutting Machine thumbnail-1

Brake Drum Lathe/Disc Cutting Machine photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Henan, China

Brand Name:

TIMAC

Model Number:

T8465

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China port.

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Henan, China

Brand Name TIMAC

Model Number T8465

Condition New

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Drum dia. 180-650mm;
2. Disc dia. 0-500mm;
3. Three spindle speed 25,40,70 .

Features:

1. Brake drum lathe T8465 is a kind of lathe. It can fulfill the reparation of the brake drum, disc and shoe of automobiles from minicar to medium trucks.

2. The brake drum/shoe can be cut on the first Spindle and the brake disc can be cut on the second Spindle.

3. This lathe has higher rigidity, accurate workpiece positioning and is easy to operate.

4. If you adopt this brake drum lathe, there is no doubt for your enterprise to set up higher reputation due to better process quality and lower your process cost.

Specification	Unit	T8465
Drum dia. capacity	mm	180-650mm
Disc dia. capacity	mm	0-500
Spindle speed (three grades)	r/min	25, 40, 70
Tool post Travel	mm	250
Feed Rate	mm/r	0.16
Motor	kw	1.1/1400
Power Requirement		380V/ 50HZ/ 3phases/3A
Dimension(not includle crane and outboard supporter)
Length	mm	800
Width	mm	875
Height	mm	940
Net Weight	kg	580
