MEDIUM SPEED WIRE CUT EDM

MEDIUM SPEED WIRE CUT EDM thumbnail-1
MEDIUM SPEED WIRE CUT EDM photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Brand Name:
TIMAC
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Brand Name TIMAC
Model Number DK-250, DK-320

Specifications

MEDIUM SPEED WIRE CUT EDM
high speed wire cut edm

MEDIUM SPEED WIRE CUT EDM


* The cast of machine body adopt the resin-sand technology with the influence of high temperature annealing.

* The travel parts of the machine adopt high quality ball screw and linear guide way.

* The structure of wire frame adopt the symmetric structure for the up and down frame to keep the tension of moly-wire within the scope of normal tension.

* Data exchange and remote control is realizable under the powerful network function of XP system.

* The system has the function of pitch correct, which can improve the position accuracy effectively.

* The wire moving is controlled by transducer, which adopts unlimited adjustment.

* The processing components involve godet mechanism, the best roughness Ra=1.5μm.

* The cooling system is equipped with a large water tank with three levels filtration.



Model Unit DK-250 DK-320 DK-400 DK-500 DK-630 DK-700 DK-800 DK-1000 DK-1000x1500 DK-1300x1500 DK-1600x1600 DK-1200x2000
Work table travel mm 250x320 320x400 400x500 500x630 630x800 700x1000 800x1000 1000x1200 1000x1500 1300x1500 1600x1600 1200x2000
Work table size mm 380x525 415x635 500x785 600x900 660x1100 760x1400 820x1400 1090x1600 1090x1700 1400x1900 1950x1950 1330x2440
Cutting depth (optional) mm 300/500 300/500 500 500 500/800 500/800 500/800 500/800/1000 500/800/1000 500/800/1000 500/800/1000 500/800/1000
Taper (optional)   0° /6° /30° /60° 0° /6° /60° 0° /6°
Roughness μm Ra(once cutting)≤2.5, Ra(Multi-cutting)≤1,5 ≤2.5
Precision mm ≤0.015 ≤0.02
Screw & guideway (optional)   Precision ball screw , precision steel plated/linear guideway High quality ball screw, Steel linear guideway
Load of table kg 300 400 500 800 3000 5000 5000 5000 6000 6000 6000 6000
Machine weight kg 1600 1700 2000 2300 4500 6000 6700 7000 7500 7800 10000 12000



  Machine model

Item A B C D E F G H I
Max. workpiece thickness(mm) 300 500 300 500 300 500 300 500 1000
Max. taper angle (within 100mm thick) 0° 0° ±3° ±3° ±30° ±30° ±15° ±15° ±3°
