600 * 900mm Table Size Medium Speed Wire Cut EDM / Wire Eroders

Name: 600 * 900mm Table Size Medium Speed Wire Cut EDM / Wire Eroders
Brand: TIMAC
SKU: 140797068
Availability: InStock

US$ 5,000 - 35,000 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

CNC

Brand Name:

TIMAC

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not CNC

Brand Name TIMAC

Model Number DK-500

Medium Speed Wire Cut EDM DK-500

Feature:

* The cast of machine body adopt the resin-sand technology with the influence of high temperature annealing.

* The travel parts of the machine adopt high quality ball screw and linear guide way.

* The structure of wire frame adopt the symmetric structure for the up and down frame

* The cast of machine body adopt the resin-sand technology with the influence of high temperature annealing.

* The travel parts of the machine adopt high quality ball screw and linear guide way.

* The structure of wire frame adopt the symmetric structure for the up and down frame to keep the tension of

moly-wire within the scope of normal tension.

* Data exchange and remote control is realizable under the powerful network function of XP system.

* The system has the function of pitch correct, which can improve the position accuracy effectively.

* The wire moving is controlled by transducer, which adopts unlimited adjustment.

* The processing components involve godet mechanism, the best roughness Ra=1.5μm.

* The cooling system is equipped with a large water tank with three levels filtration.

Parameter:

Model	Unit	DK-250	DK-320	DK-400	DK-500	DK-630	DK-700
Work table travel	mm	250x320	320x400	400x500	500x630	630x800	700x1000
Work table size	mm	380x525	415x635	500x785	600x900	660x1100	760x1400
Cutting depth (optional)	mm	300/500	300/500	500	500	500/800	500/800
Taper (optional)		0° /6° /30° /60°
Roughness	μm	Ra(once cutting)≤2.5, Ra(Multi-cutting)≤1,5
Precision	mm	≤0.015
Screw & guideway (optional)		Precision ball screw , precision steel plated /linear guideway				High quality ball screw, Steel linear guideway
Load of table	kg	300	400	500	800	3000	5000
Machine weight	kg	1600	1700	2000	2300	4500	6000

Machine model

Item	A	B	C	D	E	F	G	H	I
Max. workpiece thickness(mm)	300	500	300	500	300	500	300	500	1000
Max. taper angle (within 100mm thick)	0°	0°	±3°	±3°	±30°	±30°	±15°	±15°	±3°
