1400x400mm Bed Type Vertical Milling Machine
US$ 1,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
TIMAC
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Universal Knee Type Milling Machine UMN 250C & UMN300CNegotiableMOQ: 1 Set -
300x1250mm Vertical Knee Type Milling Machine VMN300CNegotiableMOQ: 1 Set
-
2400x650mm Large Table Size Bed Type Duplex Milling MachineUS$ 50,000 - 70,000MOQ: 1 Set
-
Bed Type Universal Milling Machine (BM715)US$ 30,000 - 40,000MOQ: 1 Set
-
Knee-type Universal Milling Machine With Swivel Milling HeadUS$ 5,000 - 20,000MOQ: 1 Set
Condition
New
Place of Origin
Henan, China
Brand Name
TIMAC
Model Number
BM714
Type
Vertical
CNC or Not
Normal
Voltage
380V/220/400V
Power(W)
7.5kw
Dimension(L*W*H)
2260x1870x2250mm
Weight
3860kg
Certification
SGS, ISO, CE
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
Bed Type Milling Machine BM714
Features:
* Large sturdy box construction and ribbed frame to reduce vibration.
* Large flat guides, hardened and ground, guarantee stability, even under heavy milling loads.
* Manual quill stroke, service is effected via a handwheel.
* Infinitely adjustable speed range(18-1800rpm) with high torque and spindle brake.
* High table load capacity(800kg) due to massive MEEHANITE cast iron construction.
| Specification | Unit | BM713 | BM714 | BM715 | BM716 |
| Spindle taper | ISO40 | ISO50 | ISO50 | ISO50 | |
| Table size | mm | 1525x320 | 1400x400 | 2100x500 | 2500x600 |
| Table travel | mm | 1050x470 | 800x400 | 1500x670 | 1500x650*700 |
| Table load | kg | - | 800 | 2000 | 3000 |
| Spindle quill travel | mm | 127 | 105 | - | - |
| NO./width/distance of T-slot | mm | 3-14-80 | 3-18-100 | 4-20-100 | 3-22-152 |
| Spindle speed steps | 10 | variable speed | 12 | 12 | |
| Spindle speed range | r.p.m | 70~3620 | 18-1800 | 35-1345 | 50-1624 |
| Distance between spindle axis and column guideway | mm | 450 | 520 | 610 | 110 |
| Distance between spindle nose and table surface | mm | 75-595 | 150-650 | 0-670 | 0-700 |
| Spindle motor power | HP | 5 | 7.5 | 7.5 | 11 |
| Overall dimension(LxWxH) | mm | 2565x1920x2290 | 2290x2040x2120 | 3300x2380x2750 | 3200x3200x2720 |
| Net weight | kg | 2520 | 3860 | 7300 | 12000 |
