Universal Tool Milling Machine / UTM400A
Features:
*Milling machine for tool construction;
*Automatic feeds on all 3 axes;
*Outer arbor supporting for horizontal milling;
*Heavily ribbed cast-iron machine stand ensures maximum static and dynamic rigidity;
*Streamlined arrangement of operating controls on the right side;
*Vertical head quill for drilling, with hand lever feed;
*Quill stroke 80mm;
*Central lubrication;
*Hardened guide ways;
*Can be equipped with Digital Position Indicator.
Parameter:
Specification | UTM300A | UTM320A | UTM400A |
Work space dimensions | 300 x750 mm | 320 x 750 mm | 400 x 800 mm |
Vertical table dimensions | 225 x 830 mm | 225 x 830 mm | 250 x 1060 mm |
T-slots,work table | 5 x 14 x 63 mm | 5 x 14 x 63 mm | 6 x 14 x 63 mm |
T-slots,vertical table | 2 x 14 x 126 mm | 3 x 14 x 63 mm | 3 x 14 x 63 mm |
Longitudinal travels(X) | 405(manual) / 395 mm | 45(manual) / 400 mm | 500 mm |
Transverse travel(Y) | 200 mm | 305(manual) / 300 mm | 400 mm |
Vertical travel(Z) | 390(manual) / 380 mm | 400(manual) / 390 mm | 400 mm |
Horizontal spindle(Min.) | 35 mm | 85 ± 63 mm | 95 ± 63 mm |
Horizontal spindle(Max.) | 425 mm | 485 ± 63 mm | 475 ± 63 mm |
Vertical spindle(Min.) |
| 85 ± 63 mm | 55 ± 63 mm |
Vertical spindle(Max.) |
| 440 ± 63 mm | 445 ± 63 mm |
Max.throat | 188 mm | 160 mm | 540 mm |
Speed range | 40-1600 r/min | 40~2000 r/min. | 40~2000 r/min. |
Spindle mount | ISO 40, Taper 7:24 | ISO 40, 7:24 | ISO 40, Taper 7:24 |
X,Y,Z axis feeds |
| 10-380 mm/min. | 10~380 mm/min. |
Rapid feed |
| 1200 mm/min. | 1200 mm/min. |
Quill stroke | 80 mm | 80 mm | 80 mm |
Main motor rating | 2.2 kw | 2.2 kw | 3 kw |
Feed motor rating |
| 3.59 kw | 5 kw |
Dimensions(LxWxH) | 1170×1210×1600 mm | 1215 x 1200 x 1800 mm | 1390 x 1430 x 1820 mm |
Weight | 1100 Kg | 1300 kg | 1400 Kg |
***Standard accessories:
*Complete tool;
*Cutter arbor (dia. Φ16, 22, 27, 32mm);
*Reducing sleeves (Morse1, 2, 3)
*Spring collect (dia. Φ2, 3, 4, 5, 6, 8, 10, 12mm)
Package: Wooden pallet & plastic cover (Standard)
or Plywood case (Optional)
Packing size:
One piece in one case: 114x122x222CM N.W./G.W.: 850/1050KGS
Two pieces in one case: 114x122x222CM N.W./G.W.: 1700/1900KGS
Container loaded: 3 sets / 20'GP
