TIMEWAY Horizontal Knee Type Milling Machine UMN420
- 60 Set / Sets per Month
- Shanghai Port
- T/T
You May Like
-
TIMEWAY Swivel Head Knee type Milling Machine US320
-
Stocking ! Universal Knee - type Milling Machine US260A
-
Fresadora / Vertical Knee Type Milling Machine For Sale ( WVM320 )
-
Universal Tool Milling Machine UTM300A
-
Ram-type Milling Machine RUM460 (Servo)
-
Ordinary Gear Hobbing Machine For Cutting Teeth
Product Details
| Condition | New | Brand Name | TIMAC | |
| Model Number | UMN420 | Type | Horizontal | |
| CNC or Not | Normal | Voltage | As client's request | |
| Power(W) | 11kw | Dimension(L*W*H) | 2460*2270*2280mm | |
| Weight | 4640kg | Certification | CE, ISO9001:2008 | |
| Warranty | 1 year after delivery |
Product Description
Horizontal Knee Type Milling Machine UMN420
Key Features:
• It is suitable to process flat, inclined surface, slots and gears on miscellaneous work pieces
• With enough rigidity, it can bear heavy processing
• Hardened and ground slide ways
• Automatic feeds on X, Y, Z axes
• Worktable can swivel ±45°
Technical Specification:
Model | UMN420 | UMN320 |
Table size (W×L) | 420×1800mm | 320×1600mm |
Table travel (X/Y/Z) - Manual | 1280×360×470mm | 1020×300×410mm |
- Auto. | 1250×350×450mm | 1000×280×400mm |
Table t-slots(No./Width/Pitch) | 3-18-90mm | 3-18-80mm |
Max.rotary angle of worktable | ±45° | ±45° |
Max.loading of worktable | 800kg | 550kg |
Spindle taper | 7:24, No.50 | 7:24, No.50 |
Spindle speed range | 30-1500r.p.m (18steps) | 30-1500r.p.m (18steps) |
Arbor diameter | φ32,φ50mm | Φ22,φ27,φ32mm |
Table longitudinal & cross feed (X/Y) | 22-1100mm/min | 15-750mm/min |
Table vertical feed (Z) | 8.3-410mm/min | 5.7-280mm/min |
Table rapid speed (X/Y/Z) | 2400/2400/900mm/min | 2250/2250/844mm/min |
Spindle nose - worktable | 30-500mm | 30-440mm |
Horizontal spindle - arm | 155mm | 155mm |
Main motor power | 11kw | 7.5kw |
Feed motor | 3kw | 1.5kw |
Overall dimensions (L×W×H) | 2522×2262×2047mm | 2327×2067×1720mm |
Packing size (L×W×H) | 2460×2270×2280mm | 2220×2180×2280mm |
N.W/G.W | 4640/5000kg | 3300/3500kg |
Price (FOB China) |
|
Standard Configuration:
End mill cutter, Cutter shaft, Arbor tension screw, Oil gun, Cooling system, Working light, General tools, Operator manual.
Options & Extra Cost:
Vertical milling head
3-axis SINO D.R.O
58pcs clamping kit
Machine vise
Dividing head
Rotary table
Package: Wooden pallet & plastic cover (Standard)
or Plywood case (Optional)
Packing size: 2.46 x 2.27 x 2.28M N.W./G.W.: 4640/5000kg
Container loaded: 2 sets / 20'GP
If you have any queries please give us a
call or send us a message.
We will be happy to assist you!
