Chinese Extra Horizontal Heavy-duty Lathe Machine
For Sale At Low Price
Features :
1. This is one type of universal lathe bearing 32 ton . It is suitable for external and internal cylinderical surface , oil grooves , cutting off , boring hole , turning inside and outside conical , cylinderical and discold parts to axes parts of different materials with high-speed steel and hard alloy steel cutters , and it can turn different kinds of screw thread with length short of 600mm with upper too-post (via change gears).
2. This machine bed structure is integral box-shaped and three strip rectangle guide way , and it is found once by high quality cast iron (HT300), through two-aged processing , stability is good; Width guideway surface (1600mm), good rigidity , strong anti-vibration ability ; It is accurate ground by import guideway grinder , which guarantee the high precision and best receptivity .
3. The machine's tool master drive institution is dragged by 75kw DC electric motor , and it adopts the mode of speed regulation of adjust magnestism commix with adjust pressure . Total ratio of speed is 1:22.2 . The institution's speed regulation progression is third class. The syntheses speed regulation ratio of mechanism and electric is 1:200, thereby made the master axes obtain infinite class speed variation scope 0.8-160 r/min.
4. Input system is connected with naked bar and master drive , made the input directness relation to speed of master axes , feeding amount selection is facility.
Parameter :
Specification |
Unit |
AL-1600H/1 |
AL-2000H/1 |
AL-2500H/1 |
Max. Swing over bed |
mm |
1600 |
2000 |
2500 |
Max. Torque of face chuck |
kg.m |
8000 |
||
Max. Length of workpiece |
mm |
3000-18000 (according to customer’s need) |
||
Swing over cross slide |
mm |
1250 |
1600 |
2200 |
Form of bed guide way |
|
3 slide way |
||
Width of bed |
mm |
1600 |
||
Spindle speed |
rpm |
0.8~160(stepless) |
||
Taper hole of spindle |
mm |
120(tapered 1:7) |
||
Face chuck diameter |
mm |
1600 |
||
Longitudinal feed range |
mm/r |
18 kinds, 0.125~48 |
||
Cross feed range |
mm/r |
18 kinds, 0.063~24 |
||
Upper tool-post feed range |
mm/r |
0.063-24 |
||
Number and range of metric thread |
mm |
2-40 |
||
Number and range of inch thread |
TPI |
1~14 |
||
Number and range of module thread |
mm |
1.5~20 |
||
Max. Travel of cross slide |
mm |
725 |
||
Max. Travel of top slide |
mm |
600 |
||
Diameter of tailstock quill |
mm |
300 |
||
Travel of tailstock quill |
mm |
300 |
||
Taper hole of tailstock quill |
mm |
100 (tapered 1:7) |
||
Main motor power |
kw |
75 |
||
Max. Weight of workpiece |
kg |
32000 |
||
