Specification | KBM-1354B | KBM-1654 | KBM-2063 | KBM-2473 | |||
Table size(L×W/mm) | 1370×330 | 1370x406 | 1600x510 | 1854x610 | |||
Table loading capacity(kg) | 400 | 800 | 1200 | 1500 | |||
T-slots(W/mm×NO) | 16×3 | 16x5 | 18x5 | 18x5 | |||
X-axis(mm) | 800 | 1000 | 1200 | 1500 | |||
Y-axis(mm) | 450 | 480 | 700 | 700 | |||
Z-axis(mm) | 480 | 600 | 600 | 700 | |||
Max.move speed(mm/min) | 8000 | 8000 | 10000 | 10000 | |||
Max.feed speed(mm/min) | 3000 | 3000 | 4000 | 4000 | |||
Spindle speed(rpm/min) | range:40~6000 |
| |||||
Spindle nose | BT40 | BT40 | BT40/BT50 | BT40/BT50 | |||
Spindle motor(kw) | 5.5 | 7.5 | 7.5 | 7.5 | |||
Servo motor(kw) | X/Y:1.0,Z:1.5 | X/Y/Z:1.5 | X/Y/Z:2.0 | X/Y/Z:2.0 | |||
Spindle quill diameter(mm) | 120 | 150 | 150/160 | 150/160 | |||
Spindle to column surface(mm) | 450 | 520 | 640 | 695 | |||
X-axis(mm) | 32×5p4Double nuts | 32×5p4Double nuts | 40×10p4Double nuts | ||||
Y-axis(mm) | 32×5p4Double nuts | 40×5p4Double nuts | 40×10p4Double nuts | ||||
Z-axis(mm) | 32×5p4Double nuts | 40×5p4Double nuts | 40×10p4Double nuts | ||||
Positioning accuracy(mm) | ±0.015 | ±0.015 | ±0.015 | ±0.015 | |||
Repeatability(mm) | ±0.008 | ±0.008 | ±0.008 | ±0.008 | |||
Packing dimension(L×W×H)(mm) | 2250×2280×2450 | 2500x2280x2650 | 2900x2950x2800 | 2900x3150x2900 | |||
Machine weight(kg) | 2600 | 3800 | 5000 | 6000 | |||
