Home > Products > Bending Machine > Special Use NC Hydraulic Three Roller Plate Rolling Machine for Ships Building or Trailer

Special Use NC Hydraulic Three Roller Plate Rolling Machine for Ships Building or Trailer

FOB Price

US$ 100,000 - 500,000 / Set

1 Set(Min. Order)

Port China Port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Brand Name	TIMAC
Model Number	HTR-12*6500C	Machine Type	Other, Coiling bending machine, Roll forming machine, Roller-bending machine
Raw Material	Sheet / Plate Rolling	Material / Metal Processed	Other, All kinds of steel sheet
Power	Cnc	Automation	Other, Semi-automatic
Extra Services	Other, Rolling cone workpiece	Certification	CE
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Special Use NC Hydraulic Three Roller Plate Rolling Machine

for Ships Building or Trailer

HTR-12*6500C HTR-20*12500S

Main Outlook

Product Description

Special Use Three Roller Plate Rolling Machine

FIRST: Ships Building (HTR-20*12500S)

Features:

S-series marine plate rolling machine, it's used to roll the radius for the shell of the boat and press the channel shape. It can be designed to different type per customer's requirement. Set the inflexibility beam at the upside of the upper roller. It has set several groups of the support roller between upper rollers and beam, and at the bottom of the lower roller to improve the stiffness of upper roller and lower roller, three rollers are driving rollers.

SECOND: Trailer (HTR-12*6500C)

Features:

C-series: The upper roller can make vertical elevation or horizontal shift. The vertical elevation is hydraulic driving, which is achieved by the action of the oil in the hydraulic cylinder on the piston; the horizontal shift is achieved through the torques from the lead screw cabinet, worm and the structure of screw and worm. The lower roller only makes rotation, providing torque for bending and rolling. On the lower side of the lower roller, there is support roller for adjustment. The upper roller is in drum shape for enhancing the straightness of the products. The machine is fit bending various cylinder bodies.

Specifications List

Technical Parameters

Ships Building

Model	Max. plate thickness (mm)	Plate width (mm)	Main motor power (kw)
HTR-20*8000S	20	8000	45
HTR-25*12000S	25	12000	55
HTR-30*12000S	30	12000	75
HTR-30*16000S	30	16000	110
HTR-40*18000S	40	18000	2*75
HTR-40*21000S	40	21000	2*75

Trailer (Three roller symmetrical plate rolling machine)

Model	Max. rolling thickness (mm)	Plate width (mm)	Diameter of upper roller (mm)	Main motor power (kw)
HTR-5*7000C	5	7000	440	11
HTR-6*9500C	6	9500	500	15
HTR-8*6000C	8	6000	420	15
HTR-8*7000C	8	7000	450	15
HTR-8*8000C	8	8000	470	15
HTR-8*9500C	8	9500	510	15
HTR-10*6000C	10	6000	440	15
HTR-10*9000C	10	9000	470	15
HTR-12*6000C	12	6000	460	15
HTR-12*9000C	12	9000	530	22
HTR-16*6000C	16	6000	500	22

Trailer (Upper roller universal plate rolling machine)

Model	Max. rolling thickness (mm)	Max. pre-rolling thickness (mm)	Plate width (mm)	Diameter of upper roller (mm)	Main motor power (kw)
UTR-9*5000C	9	7	5000	400	11
UTR-8*6000C	8	6	6000	430	15
UTR-10*6000C	10	8	6000	450	15
UTR-10*6000C	10	8	9000	530	15
UTR-12*6000C	12	10	6000	470	15
UTR-12*9000C	12	10	9000	540	22
UTR-16*6000C	16	14	6000	510	22
