Foton Brand! 4x2 Small Led Advertising Truck

Main specification

Product model,name

BJ5043XXC-B1 Mobile LED Truck

Total weight(Kg)

4495

Drive type

4 x 2

Curb weight(Kg)

4365

Overall dimension (mm)

5995×2025×2990

Wheelbase(mm)

3360

Cab seats (man)

2

Approach / departure angle(°)

23/19

Front/rear hang(mm)

1085/1550

Axle load

1710/2785

Max speed(Km/h)

95

Chassis specification

Chassis model

BJ1043V9JEA-A

Manufacturer

Beiqi Futian Motor Company Limited

Brand name

FOTON

Number of axes

2

Tire specification

6.50-16

Tires No.

6

Leaf spring

4/6+7

Front track(mm)

1415, 1525, 1545,1550

Type of fuel

Diesel

Rear track(mm)

1485, 1525

Emission standard

Euro IV

Transmission

5 Forward Gear

Driving cab

Engine model

Engine Manufacturer

Displacement(ml)

Power(KW)

4B2-95C40

ANHUI QUANCHAI ENGINE CO.,LTD

2545

70

Mobile LED truck specification

LED screen size

(length x high)(mm)

3840 x 1760

Led side screen area(M2)

6.8

Screen Lift Height(m)

1.5

LEDscreen’s pixel pitch(mm)

10

RollerScreen Size(M2)

6.8

Rear monochrome screen size(M2)

1.84

Remark

There be equipped the Silent generator, wooden floors, lighting, ventilation fans, skylights, computers, stereos, amplifiers and other facilities within the body , and 220V external power connector outside the body. According to customers' requirements, it can be equipped the LED screen lifting system and hydraulic extenstion stage, which will be a multi-purpose truck.

[The Main Features of LED truck]

1. This truck is a special vehicle for advertising, generally used for the product promotion, brand promotion, draft activities , live shows sales, sporting events, vocal concerts, concerts and so on!
2. Can be showing at any time, communication, interaction, publicity coverage extensively. And meanwhile effectively get the best of advertising effect,,
3. According to own requirement. you can select the left and right sides and the back medium(include LED full color, Monochrome LED, Light box advertising) , Led full colour screen can be chose P10, P8, P7, P6.
