HOWO 4x2 LED TRUCK , Mobile Outdoor Truck and moblie truck FOR OUTDOOR ADVERTISING

Main specification

Product model,name

SGZ5047XXCZZ4 Mobile LED Truck

Total weight(Kg)

4495

Drive type

4 x 2

Curb weight(Kg)

4300

Overall dimension (mm)

5995×2025×2995

Wheelbase(mm)

3360

Cab seats (man)

3

Approach / departure angle(°)

20/13

Front/rear hang(mm)

1160/1475

Axle load

1790/2705

Max speed(Km/h)

90

Chassis specification

Chassis model

ZZ1047C3414D145

Manufacturer

China National Heavy Duty Truck G roup Co., Ltd

Brand name

HOWO

Number of axes

2

Tire specification

7.00-16

Tires No.

6

Leaf spring

3/5+3,8/9+6,11/9+7,11/11+7

Front track(mm)

1605

Type of fuel

Diesel

Rear track(mm)

1520

Emission standard

Euro IV

Transmission

5 Forward Gear

Driving cab

Engine model

Engine Manufacturer

Displacement(ml)

Power(KW)

4DW93-84E4

FAWCarCo., Ltd. WuxiDiesel Engine Factory

2540

64

Mobile LED truck specification

LED screen size

(length x high)(mm)

3840 x 1760

Led side screen area(m2)

6.8

Screen Lift Height(m)

1.5

LEDscreen’s pixel pitch(mm)

10

RollerScreen Size(m2)

6.8

Rear monochrome screen size(m2)

1.84

Remark

There be equipped the Silent generator, wooden floors, lighting, ventilation fans, skylights, computers, stereos, amplifiers and other facilities within the body , and 220V external power connector outside the body. According to customers' requirements, it can be equipped the LED screen lifting system and hydraulic extenstion stage, which will be a multi-purpose truck.

[The Main Features of LED truck]

1. This truck is a special vehicle for advertising, generally used for the product promotion, brand promotion, draft activities , live shows sales, sporting events, vocal concerts, concerts and so on!
2. Can be showing at any time, communication, interaction, publicity coverage extensively. And meanwhile effectively get the best of advertising effect,,
3. According to own requirement. you can select the left and right sides and the back medium(include LED full color, Monochrome LED, Light box advertising) , Led full colour screen can be chose P10, P8, P7, P6.
