SINOTRUK HOWO 6X4 12000liter Water Tank Fire Truck for Sale

Main specification

Product model and name

JDF5280GXFSG120Z Water tank fire fighting truck

Gross weight(Kg)

27600

Drive type

6X4

Payload(Kg)

12350

Overall dimension(mm)

10025×2500×3600

Curb weight(Kg)

14800

Cab seats

6

Approach/departure angle(°)

16/13

Front/rear hang(mm)

1500/2490

Axle No.

3

Wheelbase(mm)

4600+1350

Axle load(Kg)

6900/20700

Max speed(Km/h)

85

Chassis specification

Chassis model

ZZ1257M4647C

Manufacturer

China SINOTRUK Group Jinan Truck Co.,Ltd

Brand name

SINOTRUK(HOWO)

Dimension(mm)

9895×2496×2958

Tyre specification

11.00-20

Tyre No.

10

Steel spring number

10/12

Front track base(mm)

2022

Fuel type

Diesel

Rear track base(mm)

1830

Emission standard

Euro 3

Transmission

10 forward gear,2 reverse gear

Cab

Four opening doors and whole flat top with crew cab, and all steel frame welded structure, hydraulic turnover mechanism with air condition

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

Horsepower(HP)

WD615.97E

China Heavy Duty Truck Group Co.,Ltd

9726

221

300

Water tank fire fighting truck performance

Water tank volume(L)

12000 to 15000

Fire monitor

Fire monitor model PS50, level rotation by 360º,

Max elevation +45º, Max angle of depression -15º,

Flow rate:50L/S,Range≥60m/1.0MPa

Fire pump

Model:CB10/60 Flow rate:60L/S  Pressure:1.0MPa

Water tank fire truck Feature

A.The water tank fire fighting truck is mainly made up of the cab,water tank,water pump house,equipment boxes,water pump,and inlet and outlet water system,fire monitor,electronic alarm,alarm lamp etc.parts.

B.The entire distribution of truck is divided into three parts.The front part is passenger room.The middle part is pump house.The rear part is the truck body.The front part of car body is water tank,the rear part is equipment box.

C.It has the feature of high power,high speed and big carrying liquid capacity etc.It is adopted the extended cab.With seat comfortably and centralized operation,simple maintenance,

D.it is widely used in the public security fire brigade, the petroleum chemical industry, factories and mines enterprises and ports, terminals and other places to save the large of oil fire and general material fire in large and medium-sized cities.It is the ideal large fire-fighting equipment.

1.About the package of our trucks,usually it is nude that covered with wax.And it also can be packed as your need.

2.About the shipping,there are many ways,such as Ro-Ro Ship / Bulk transport / Container packing / SKD / etc. And it can be offered according to your request.
