Foton 4X2 1000L Mini Fire Truck Sale

Main specification

Product name

Gross weight(Kg)

5495

Drive type

4X2

Payload(Kg)

1250

Overall dimension(mm)

6260x1900x2750

Curb weight(Kg)

3870

Cab seats

2

Approach/departure angle(°)

19/12

Front/rear hang(mm)

1032/1928

Axle No.

2

Wheelbase(mm)

2300

Axle load(Kg)

2470/3025

Max speed(Km/h)

85

Chassis specification

Chassis model

BJ1022V3JA2-S

Manufacturer

Foton Motor Co.,Ltd

Brand name

FOTON

Dimension(mm)

 ***

Tyre specification

6.00-14

Tyre No.

6

Steel spring number

8/9+5

Front track base(mm)

1404

Fuel type

Diesel

Rear track base(mm)

1458

Emission standard

Euro 3

Transmission

5 forward gear,1 reverse gear(Oil brake)

Cab

Single row cab and can be tippable forwardly. Air condition is optional.

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

Horsepower(HP)

4D18F

Anhui Quanchai Power Co.,Ltd

1809

40

55

Water tank fire fighting truck performance

Water tank volume(L)

1000

Fire monitor

Fire monitor model PS20, level rotation by 360º,

Max elevation +45º, Max angle of depression -15º,

Flow rate:40L/S,Range≥40m/1.0MPa

Fire pump

Model:CB10/20 Flow rate:20L/S    Pressure:1.0MPa

Water tank fire truck Feature

A.The water tank fire fighting truck is mainly made up of the cab,water tank,water pump house,equipment boxes,water pump,and inlet and outlet water system,fire monitor,electronic alarm,alarm lamp etc.parts.

B.The entire distribution of truck is divided into three parts.The front part is passenger room.The middle part is pump house.The rear part is the truck body.The front part of car body is water tank,the rear part is equipment box.

C.It has the feature of high power,high speed and big carrying liquid capacity etc.It is adopted the extended cab.With seat comfortably and centralized operation,simple maintenance,

D.it is widely used in the public security fire brigade, the petroleum chemical industry, factories and mines enterprises and ports, terminals and other places to save the large of oil fire and general material fire in large and medium-sized cities.It is the ideal large fire-fighting equipment.

1.About the package of our trucks,usually it is nude that covered with wax. And it also can be packed as your need.

2.About the shipping,there are many ways,such as Ro-Ro Ship / Bulk transport / Container packing / SKD / etc. And it can be offered according to your request.
