7KVA Air Cooled Small Portable Diesel Generator
| Model | YM9900T |
| Rated frequency | 50 60 |
| Rated output(kVA) | 6.5 6.7 |
| Max. output(kVA) | 6.7 7.0 |
| Rated Voltage(V) | 230 or as requested |
| Rated current (A) | 26 |
| Rated rotation speed(r/min) | 3000 3600 |
| Phase NO. | Single phase |
| Power factor(Cos Φ) | 1 |
| Insulation Grade | B |
| Pole number | 2 |
| Excitation mode | Self-excitation & constant voltage (AVR) |
| Panel Type | General Panel |
| Voltage(V) | 230 or as requested |
| Receptacle | Two receptacles |
| Connection pole | Without |
| DC12V output | Connection pole output |
| Overall dimension(L×W×H)mm | 930×530×740 |
| Dry weight(kg) | 172 |
| Working assorting weight | 187 |
| Noise level(7m)dB(A) | 68 |
| Structure type | Silent type |
| Engine Model | New YM192FG |
| Engine Type | Single cylinder, vertical, four-stroke, direct injection |
| Cylinder NO.-bore×stroke(mm) | 1-92×75 |
| Displacement(ml) | 548 |
| Rated power[KW/(r/min)] | 8.0/3000 |
| Compression ratio | 19:01 |
| Rated rotation speed(r/min) | 3000 |
| Cooling system | Air cooled |
| Combustion system | Direct injection |
| Starting system | Electric starter |
| Fuel type | 0#(summer)-10#(winter)-35#(chillness)diesel |
| Lube oil brand | CD grade or SAE10W-30,15W-40 |
| Lube capacity(L) | 1.65 |
| Starting motor capacity( V-kW) | 12V 0.8kW |
| Charging generator capacity ( V-A) | 12V 3A |
| Battery capacity(v-Ah) | 12V 30-36Ah |
| Fuel consumption(g/kw.h) | ≤360 |
| Fuel tank capacity(L) | 15 |
| Continuous running time(hr) | 6 |
