High Performance Diesel Generator KDE3500E

Name: High Performance Diesel Generator KDE3500E
Brand: Sumokama
SKU: 140760128
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

KDE3500E

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KDE3500E

Output Type AC Single Phase

Speed 3000/3600

Frequency 50/60

Rated Power 2.8/3.0

Rated Voltage 115/230 120/240

Rated Current 24.4/12.2 25/12.5

Specifications

Large bottom fuel tank to ensure long working time
Key start
Full control panel with power indicator light, fuel light

Model	KDE3500E
Frequency (HZ)	50	60
Rated Output (KVA)	2.8	3.0
Maximum Output (KVA)	3.0	3.2
Rated Voltage (V)	115/230	120/240
Rated current (A)	24.4/12.2	25/12.5
Rated rotation speed (rpm)	3000	3600
Phase No.	Single phase
Power Factor	1.0
Excitation Mode	Self-excitation, 2 pole and constant voltage (AVR)
DC Output	12V./8.3A ,Terminal Post
Noise Level (7m) dB(A)	72
Engine Model	KM178FE
Engine type	Single-Cylinder, Vertical, Four-Stroke, Direct Injection,Air Cooled Diesel
Bore × Stroke(mm)	78 x 62
Displacement (L)	0.296
Rated Power KW	3.68/3000	4.0/3600
Fuel comsumption Rate(g.kw/h)	276.1	285.6
Compression Ratio	20:1
Lubrication System	Pressure Splashed
Starting System	Electric Start with 30Ah MF battery
Fuel Type	0#(summer)-10#(winter) diesel
Lube Oil Brand	SAE10W30 (above CD Grade)
Lube Capacity (L)	1.1
Fuel Tank Capacity (L)	12.5
Continuous Running Time (hr)	12
Overall Dimension: LxWxH (mm)	710 x 500 x 590
Dry Weight (Kg)	70
Quantity in 20FT	132 Pcs
Optiomal Features: Remote,ATS(Auto Transfer Switch) ,Digital Panel
We reserve the right to change specifications without notice
