10kva Air Cooled Diesel Generator

Name: 10kva Air Cooled Diesel Generator
Brand: Sumokama
SKU: 140760136
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

KDE12000E/KDE12000E3

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KDE12000E/KDE12000E3

Output Type Other, Single/Three

Speed 3000/3600

Frequency 50/60HZ

Rated Power 10-11/11-12

Rated Voltage 230/240 400/230

Rated Current 43.5/45.8 15.9/16.7

Specifications

10kva air cooled diesel generator
stable operation,low vibration and low noise
high efficiency
very durability,

Model	KDE12000E			KDE1200E3
Rated frequency Hz	50	60		50	60
Rated output power kVA	10	11		11	12
Max. power kVA	11	12		12	13
Rated voltage V	230	240		400/230	400/230
Rated current A	43.5	45.8		15.9	16.7
Phase No.	Single			Three
Power factor (cosφ)	0.9 (lag)			0.8 (lag)
Insulation	F
Pole No.	2
Exciting mode	Brush, exciting-self voltage-constant (with AVR)
DC12V output	12V, 8.3A
Dimensions:L×W×H (mm)	870×630×700
Net weight (Kg)	195
Noise (7m)dB(A)	82
Engine model	R2V840
Engine Type	V-twin, two-cylinder, four-stroke, Direct injection
Cylinder No. –bore ×stroke (mm)	2-86×72
Total displacement (ml)	836
Compressed ratio	20:1
Cooling type	Air Cooled
Lubricating type	Pressure & splashing
Starting type	Electric Start
Fuel Type	0 # (summer) -10 # ( winter) -35 # (cold winter) light diesel
Oil Type	SAE10W30 (CD grade above)
Lubricating oil capacity (L)	1.7
Starting motor capacity V-kW	12V 1.4kW
Battery capacity V-Ah	12V 45AH
Fuel consumption under full loading (L/H)	3.5		4.0	3.5	4.0
Fuel tank capacity ( L)	25
Continuous running time (Hr)	7.1		6.5	7.1	6.5
