10kw Diesel Generator

Name: 10kw Diesel Generator
Brand: Sumokama
SKU: 140760138
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

KDE10E

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KDE10E

Output Type AC Single Phase

Speed 3000/3600

Frequency 50/60

Rated Power 10/11

Rated Voltage 230

Rated Current 41.3/45.7

Specifications

10kva air cooled diesel generator
stable operation,low vibration and low noise
high efficiency
very durability,lightweight

Model	KDE10E
Rated frequency(Hz)	50	60
Rated Voltage(V)	230	230
Rated Current (A)	41.3	45.7
Rater Output (kW)	10	11
Max Output (kW)	11.5	12.5
Rated rotation speed(rpm)	3000 3600
Power factor	1
Phase number	Single phase
Excitation mode	Self-excitation and constant voltage (AVR)
Starting mode	Electrical start with start motor
DC output	12V 8.3A
Noise level dB(A)7m	79-85
Fuel tank capacity(L)	25
Continuous running time (hr)	8
Overall dimension(LWH)(mm)	1250620805
Dry weight(kg)	210
Engine model	KM290
Engine type	Two cylinder in-line,air-cooled,4-stroke, direct injection, diesel engine
Bore*stroke(mm)	90x75
Total displacement (L)	0.954
Rated Power [kW(HP)/rpm]	13.5(18.3)/3000	14(19.0)/3600
Fuel type	0#(summer)-10#(winter)light diesel oil
Fuel consumption rate(g/kW.h)	270	290
Lube oil brand	LECD grade 15W40
Lubrication oil volume(L)	3.15
Compression ratio	19:1
Cooling system	Forced air-cooled
