320HP Bulldozer WD8B

Name: 320HP Bulldozer WD8B
Brand: WORLD
SKU: 140752802

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

WORLD

Model Number:

WD8B

World Heavy Industry (China) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name WORLD

Model Number WD8B

Condition New

Moving Type Crawler Bulldozer

Machine Weight 37400KGS

Dimension(Long * Breadth * High) 7751x3940x3549mm

After-sales Service Provided Overseas service center available

Specifications

320HP Bulldozer WD8B
1)Cummins engine
3)3Forward and 3 Reverse
4)Rops cabin
5)Single shank Ripper

320HP Bulldozer WD8B
Engine Model	Cummins NT855-C360S10
Type	Straight vertical, 4 stroke, water cooling, PT pump injection, turbocharged
Flywheel power	235 kw
Rated speed	2100 rpm
Air cleaner	Dry horizontal type with precleaner
Min fuel consumption ratio	less than 235 g/kw.h
Transmission system
Torque converter	Power seperating hydraulic-mechanic type
Transmission	Hydraulic shift, planetary gear, multiple disc clutch, forced lubrication by gear pump, 3 forward and 3 reverse speeds
Steering clutch	Wet,Hydraulic pressed,non-constant engated
Steering brake	Wet,Hydraulic pressed by spring,seperated hydraulic, constant meshed type
Final drive	Two-stage planetary reduction gear mechanism, splash lubrication
Working hydraulic system
Working pressure	22.5 Mpa
Rated flow	220L/min (2100rpm)
Pump	High pressure gear pump
Track
Type	Delta type,Sprocket is elevated
Track pitch	216 mm
Track width	560 mm
Length of track on ground	3280 mm
Ground clearance	556 mm
Track gauge	2083mm
Travel speed
Forward speed	3.5/6.2/10.8 km/h
Reverse speed	4.7/8.1/13.9km/h
Under carriage
Spocket	Segmented
No. of track rollers each side	8
Track tension	Hydraulic-adjusted
