PD320Y Bulldozer
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
WORLD
Model Number:
PD320
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
WORLD
Model Number
PD320
Condition
New
Moving Type
Crawler Bulldozer
Specifications
PD320Y track type bulldozer is design and manufacture technology is solely imported from D155A-1 track type bulldozer of KomatsuPD320Y track type bulldozer is design and manufacture technology is solely imported from D155A-1 track type bulldozer of Komatsu. Efficient and Economic, Cummins NTA855-C360 engine with strong traction and low fuel consumption. High efficient in hydraulic mechanical transmission system, excellent function in steering hydraulic operating system, alleviating operation tiredness and improving work efficiency. Comfortable driving operation, hexagon cab, innovative in model, and wide in eyeshot, applying the latest achievement of mechanical and electrical integration with three-stage alarm electron monitor system to ensure machines operating normally. Most reasonable operation system, controlling more conveniently, nimbly and conveniently.
| Engine | |
| Model | Cummins NTA855 |
| Type | Vertical,four-stroke |
| Rated power | 239kw |
| Rated speed | 2000rpm |
| Implement Hydraulic System | |
| Hydraulic flow rate | 335L/min |
| Hydraulic pressure | 13.7Mpa |
| Pump type | Double gear pump |
| Control valve | Hydraulic operated pilot control |
| Under Carriage System | |
| Sprocket | Segmented |
| Number of track rollers(each side) | 7(5 single,2double) |
| Number of carrier rollers(each side) | 2 |
| Number of front idler(each side) | 1 |
| Track type | Single grouser |
| Track tension | Hydraulic |
| Track pitch | 228.6mm |
| Track width | 560mm |
| Number of track shoes (each side) | 41 |
| Track length of ground | 3150mm |
| Ground clearance | 500mm |
| Main Technical Specifications | |
| Operation weight(without ripper) | 35900kg |
| Ground pressure (without ripper) | 0.094Mpa |
| Grade ability | 58% |
| Overall dimensions(L×W×H) | 6600×4130×3820mm |
| Max.tractive force | 281KN |
