Lower Price YD160S-5 160Hp Wet Type Hydraulic Crawler Dozer
MAIN FEATURES:
Pass the test and inspection of the relevant national authorities, with its safety, noise, engine discharge and reliability figures meeting the requirement of the national standard, technical performance of the advanced level of the similar domestic models.
Use D6114engine jointly made by Shanghai Diesel and Austrian AVL as the auxiliary power, with such advantages as los oil consumption, little smoke, big torque reserve coefficient and high attractive force of the whole unit.
The operation system is designed based on ergonomics, incorporate the operation handles on both sides of the driver based on the function, and adopts pilot control for the working unit, greatly improving the driving comfort.
Hexahedral cab equips with high-class damping seat chair, rear view glass with armrest and adjustable for forward, backward, upward and downward direction, reducing fatigue whilst improving productivity.
Electromechanically integrated and automatic electronic monitoring system is applied for real time monitoring for completion machine; the system is applied for class alarm to assure normal operation for machine.
Each maintenance center has humanized design, improving the convenience of repair and maintenance.
Several devices such as direct-pouring shovel, environmentally hygienic, angle shovel; coat-pushed shovel and soil scarifler are available for user.
Standard heating and ventilation equipment, air conditioner is optional.
Main Specification:
Model |
|
YD160S-5 |
Total weight |
Kg |
17500 |
Max towing force |
Kn |
154 |
Track gauge |
Kw |
128 |
Engine rated speed |
r/min |
1850 |
Track gauge |
Mm |
1880 |
Caterpillar track ground length |
Mm |
2570 |
Caterpillar track board width |
Mm |
500 |
Land pressure |
Kpa |
65 |
Overall dimension |
Mm |
5900X3600X3288 |
Bulldozer shovel |
Mm |
3274X1160 |
Towing force |
|
30° |
Slope angle |
|
30° |
Start performance |
°C |
UP-10° |
Min turning radius |
Mm |
4200 |
Min ground clearance |
Mm |
350.5 |
Forward five-step driving speed |
Km/h |
3.29-9.63 |
Backward four-step driving speed |
Mm |
4.28-12.53 |
Max lifting height of bulldozer shove |
Mm |
955 |
Max in-soil depth of bulldozer shove |
mm |
552 |
