Green House Trator Bigger Power 50hp,kinds of Implements Can be Fitted

Green House Trator Bigger Power 50hp,kinds of Implements Can be Fitted thumbnail-1
Green House Trator Bigger Power 50hp,kinds of Implements Can be Fitted photo-1
US$ 2,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Weifang Haotian Farm Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Garden Tractor
Certificate EPA
Brand Name haotian
Model Number HT304
Place of Origin Shandong, China

Specifications

bigger power with 50HP.
high quality and competitive price

Tractor

Brief



   TY 4WD Gardening Tractor, in another name of 4WD Greenhouse King Tractor, is suitable for gardening, greenhouse, lawn and family work. It is assembled with creeping shift, double stage clutch, dual-way hydraulic output and hydraulic steering, which is popular in international market. With the characteristic of compact structure, mini size, reasonable power, various function, easy operation, reliable performance and enviroment protection, it is a right tractor for famiy and small farm for agriculture and gardening.
    It assembled wit3T30diesel engine, 22.06 kw with or without EPA certificate. Many options are available according to users requirments: single stage clutch or double stage cultch, (3+1)×2 gearbox or  (4+1)×2 gearbox, creeping shift (with 8 shifts gearbox), single speed PTO or double speed
PTO, dual-way hydraulic output, ROPS and sunshine shield.



 Main Technical Specification



Model

TY304B-1



Type

4×4 Wheeled type





 Length

2589





 Width

1230





 Height

1228



Dimensions



 Front wheel

1000



of Tractor(mm)

Tread

 Rear wheel

960





 Wheel base

1670





Min. Ground Clearance

215









2.9





One-side braking



Min. Radius of Turning Circle(m)


No brsking

3.3



 Dry Mass(kg)

1100



Engine

Model

LD3T30



Type

3-cylinder, Vertical, Water Cooled and 4-Stroke



Bore×Stroke(mm)

85×90



Displacement(L)

1.532



Rated Power(KW)

22.06



Rated Rev.(r/min)

2400



Max. Torque(nm)/Rev.(r/min)

89/1650



Min. Consumption(g/kw*h)

238



Dimensions (mm)

567× 494× 610



Dry Mass(kg)

180



Fuel

Diesel



Clutch



Single Disc, Dry-friction, Single Stage/Double
Stage Clutch



Transmission

(3+1)×2 or (4+1)×2or(4+1)×2×2Mechanical Type



Steering

Mechanical Type or Hydraulic Type



Hydraulic Output

Single -way output or single/dual-way quick couplingoutput



Suspension



Post Positioned Tri-point Suspension, Catalogue O



Type



PTO

Type and Rev.(r/min)

Single speed Non-independent type540 or double speed Non-independent Type 540/1000,540/720 or Semi-independent double speed type 540/1000,540/720













Spline Size (mm)

Post positioned I35 Rectangle Spline with 6 teeth (6×28.91×34.79×8.69)




Forward

1.77-26.98



Theoretical Speed (km/h)

Reverse

0.33-5.02



Tyre

Front Wheel

5.00-12



Rear Wheel

9.50-16



Structure and specification are subject to change without notice.
