Mini Gardden Tractor 20-35hp ,with Less Than 1100mm Height

Mini Gardden Tractor 20-35hp ,with Less Than 1100mm Height thumbnail-1
Mini Gardden Tractor 20-35hp ,with Less Than 1100mm Height photo-1
US$ 2,600 - 3,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Weifang Haotian Farm Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate Other, CCC
Brand Name HAOTIAN
Model Number GH304
Place of Origin Shandong, China

Specifications

Small Tractor
Tractor,18hp-35hp,4WD with famous engine
Tractor with competitive price
Tractor with stable performance

Mini gardden Tractor 20-35hp ,with less than 1100mm heightMini gardden Tractor 20-35hp ,with less than 1100mm heightMini gardden Tractor 20-35hp ,with less than 1100mm heightMini gardden Tractor 20-35hp ,with less than 1100mm heightMini gardden Tractor 20-35hp ,with less than 1100mm heightMini gardden Tractor 20-35hp ,with less than 1100mm heightMini gardden Tractor 20-35hp ,with less than 1100mm height

Wheel Tractor:



We manufacture 18-35hp wheel tractor.



Model: GH304





Our factory manufacture wheel tractors ranging from 18hp to 35 hp.





Model

TY250

TY280

TY300




Type

4×2 Wheeled Type



Dimensions Of Tractor(mm)

Length

2430



Width

1230



Heigth

1070



Tread(mm)

Front Wheel

960




Rear Wheel

980




Wheel Base

1473



Min.Ground Clearance(mm)

277




Min.Turning Radius(mm)

One-side braking

2.4




No Braking

2.8




Structural Weight

900



Engine

Model

295 or 385

2100

2102 or 3T30



Type

Vertical,2-cylinder/3-cylinder,water cooled and 4-stroke




Rated Power(kw)

18.4

20.58

22.06




Rated Speed(rpm)

2400




Fuel

Diesel




Connection Between Engine and Clutch

Shaft Connection




Clutch

Single Disc,Dry-friction,Single stage



TransmissionBox

(3+1)×2 or (4+1)×2 Mechanical Type



Steering

Mechanical Type



Suspension Type

Post Postitioned Tri-point Suspension,catalog O




PTO

Type and Speed

Single Speed Non-independent Type540 or double speed Non-independent540/1000




Spine Size

Post Postitioned I 35Rectangle Spine with 6 teeth(6×28.91×34.79×8.69)
