Farm Tractor TY300

Farm Tractor TY300 thumbnail-1
Farm Tractor TY300 photo-1
US$ 2,000 - 3,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Walking Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Weifang Haotian Farm Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Walking Tractor
By wheel 2WD
Usage Farm Tractor
Certificate EPA
Brand Name HAOTIAN
Model Number TY300
Place of Origin Shandong, China

Specifications

Tractor
1) high transmission efficiency
2) high traction,high adaptability
3) easy start
4)low tremble

Tractor

   This series product is a middle and small hp tractor directly connected with its engine. It has the characteristics of high transmission efficiency, low tremble, high traction, high adaptability and easy start, it is the upgraded generation shift product. Jaw type differential lock can improve the pass-ability. Hydraulic output interface can make direct connection with the dump trailer. This series tractor can have many different configurations according to customers demands: single stage clutch or two stage clutch, (3+1) ×2 six shifts or (4+1) ×2 eight shifts in which the creeping shift can be selected, one or two standard PTO rev., fixed or adjusted tread, back catalogue 0 or 1 suspensions.

Main Technical Specifications

 Model

TY300

 Type

4×2    2WD



Length

2654/2767



  Width

1296/1596



 Depth

1365/1414

mm

Wheel base

 Front wheel

950 or 1270fixed or 970~1270 adjustable

 Main Dimensions of Tractors

 Rear wheel

1300 fixed  or 1000~1300 adjustable

 Tread

1465/1559

Min. Ground Base

330

kgDry Mass

1010-1060

Engine

Model

2102

Type



(kw)

22.06

Rated Power

Rated rev.(r/min)

2400

Fuel

  Diesel Oil

Tyre

Front tyre

4.50-16/5.00-16



Rear tyre

9.5-24

Clutch

Dry-friction, Single Stage or Dry-friction, Two Stage

Steering

 Mechanical Type

Gearbox

(3+1)×2 or (4+1)×2

Suspension Type



Post Postitioned Tri-point Suspension Catalogue O or I



Type and Rev(r/min)

 Non-independent Type 540 or Non-independent Type 540/1000, 540/720 or             Semi-independent Type 540/1000,540/720

PTO Shaft



Spline

I35 Rectangle Spline with 6 teeth6×28.91×34.79×8.69

Structure and specification are subject to change without notice.
