Reliable 20.6m Dongfeng Aerial Platform Truck

Main features:

 Imported electro-hydraulic ratio control valve, stepless speed regulation

 Ground and basket electro-hydraulic control

Little folding beam, outreach widely

Large load capacity of platform (300kg)

Telescopic lifting beam, higher lifting height

 Lifting capacity 3000kg

 Function of position restriction, alarm in dangerous working status, highsecurity performance

 Large span of triggers, higher stability, triggers can be operated simultaneously or respectively

 Urgent power

 Inter-lock performance, safe and reliable operation.

PLATFORM INFORAMTION

Model CLQ5112JGKB

Chassis model DFL1120B

Rated load of platform 300kg

Max. working height 20.6m

Max. outreach 9.7m

Sewing speed 0-2r/min

Max. run speed 90km/h

Number of people 6

Size 9250×2500×3850

CHASSIS INFORMATION

Approach /Departure Angle(°) 20/10

F/R Suspension(mm) 1430/2645

Wheelbase(mm) 5000,4700

Axle 2

Axle Load (mm) 4135/7360

Spring Leaf 7/9+6,8/10+8

Tyres 6

Tyre Specification 9.00-20,9.00R20,10.00-20,10.00R20

Drive System 4*2

Gross/ Ratio /Kerb Mass(Kg) 11495/190/11300

Front/Rear Truck 1880/1800,1860

Other Front extend 320mm Back155mm;

Brake system Pneumatic, exhaust brake

ENGINE

Model ISDe180 30

Manufacturer CUMMINS

Fuel diesel

Speed(km/h) 85

Displacement (Ml) 4500

Power(Kw) 132

Emission Standard EU3

Torque(Nm)/Rpm 650/1400

Stroke Type Turbocharger intercooler
