1.2-2.0 Ton Full Battery Stacker With American CURTIS Electric Controller

1.2-2.0 Ton Full Battery Stacker With American CURTIS Electric Controller thumbnail-1
1.2-2.0 Ton Full Battery Stacker With American CURTIS Electric Controller photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name GP
Model Number ERC112
Type Powered Pallet Truck
Power Souce DC Motor
Rated Loading Capacity 1200kg
Max. Lifting Height 4800mm
Min. Lifting Height 3000mm

Specifications

1. German Hoppecke battery
2. ISO and CE certificates

1). FULL ELECTRIC STACKER (DC Power)



2). Advantage



1.Conforms To The Standards Of En1726-1:1999and En1175-1:1998
2.High Stability And Flexible Operation
3.Smooth stepless speed control from CURTIS
4.Low Noise, No Pollution, And High Reliability
5. Power unit and drive wheel made in Europe, . Large Capacity Battery Makes The Stacker Work Longer
7.Top-Quality Control System - CURTIS from USA or ZAPI / SME from Italia



3).Detailed specification



Specification Unit ERC112 ERC115 ERC116 ERC118 ERC120
General Rated capacity Kg 1200 1500 1600 1800 2000
Load center  mm 600 600 600 600 600
Drive type   Standed
Motor brake    Electromagnetic
Load distance (centerline of front axle to front face of forks)   716 716 716 716 716
Battery weight Kg 200 200 200 280 280
Self weight Kg 1080 1105 1130 1250 1280
Full Load per Axle - Driving side / bearing side   865/215 885/220 905/225 1000/250 1025/255
Empty Load per Axle - Driving side / bearing side Kg 970/1310 1110/1495 1095/1635 1300/1750 1400/1880
Dimensions Lifting Height (standard) mm 3000
Fork min. ground clearance mm 85
Adjust width of fork (standard) mm 570
Fork size mm 60/180/1150
Minimum ground clearance mm 25
Overall length mm 1940 1940 1940 1970 1970
Overall width mm 850 1050
Overall height (including handle ) mm 1465 1465 1465 1465 1465
Bodywork height mm 845 845 845 845 845
Overall height mast raised mm 3530 3530 3530 3530 3530
Overall height mast lowered mm 2055 2055 2055 2055 2055
Front wheel tread mm 390 390 390 390 390
Supporting wheel tread mm 708 708 708 800 800
Minimum turning radius mm 1630 1630 1630 1630 1630
Stacking right angle aisle width mm 2236 2236 2236 2270 2270
Performance Max. driving speed   full/empty Km/h 5/6 5/6 5/6 5/5.8 5/5.5
Max. lifting speed   full/empty mm/s 110/130 95/130 90/130 80/120 80/120
Max. declining speed   full/empty mm/s 120/110 110/100 110/90 80/90 80/90
Grade ability full/empty % 5/8 5/8 5/8 5/8 5/8
Wheel Wheels material   Polyurethane
Wheel number (front/rear)   4/3
Drive wheel (mm)   φ252x87 φ252x87 φ252x87 φ252x87 φ252x87
Load wheel (mm)   φ80x70 φ80x70 φ80x70 φ80x70 φ80x70
Balance wheel (mm)   φ150x48 φ150x48 φ150x48 φ150x48 φ150x48
Wheelbase   1295 1295 1295 1295 1295
Power and Control Travel motor KW 1.2 1.2 1.2 1.2 1.2
Lift motor KW 2.2 3 3 3 3
Voltage V 24 24 24 24 24
Battery capacity Ah 210 210 210 280 280
Control system    CURTIS / ZAPI / SME
Sound level at the driver's ear acc. to EN12053 dB/(A) 67





 1.2-2.0 Ton full battery stacker with American CURTIS electric controller1.2-2.0 Ton full battery stacker with American CURTIS electric controller1.2-2.0 Ton full battery stacker with American CURTIS electric controller1.2-2.0 Ton full battery stacker with American CURTIS electric controller1.2-2.0 Ton full battery stacker with American CURTIS electric controller1.2-2.0 Ton full battery stacker with American CURTIS electric controller
