1000-2000kgs Electric Reach Truck

Shanghai Gather Power Industry Co., Ltd.
1000-2000kgs Electric Reach Truck thumbnail-1
1000-2000kgs Electric Reach Truck photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name GP
Model Number TF10/TF15/TF20
Type Other, electric reach truck
Power Souce Other, 48V
Rated Loading Capacity 1000KG
Max. Lifting Height 9500mm
Min. Lifting Height 3000mm
Fork Length 1070mm
Fork Width 100mm
Overall Dimensions 2280mm
Certification ISO&CE
After-sales Service Provided Overseas service center available

Specifications

1.CURTIS electric controller
2.Stand on type
3.CE and ISO certificates



Product Information:

>> Features

The relaxed work brings the high efficiency.
Field of vision broad mast.
The intelligent dynamic system provides the safe movement.
Engineer may through forklift's on diagnosis connection read performance data.Causes the adjustment forklift performance parameter, the foresighted maintenance and the fast repair becomes very convenient..
The forklift must maintain the gap to amount to for 1000 hours.
Man-machine work efficiency. The set exercises the control, the choice of direction, the autoreversal applies the brake the multi-purpose operating handles, cause the operation to be more precise, the efficiency is higher, the pilot fatigue is lowest.
Leans the station operation, as well as the layout reasonable operating handle, reduces the pilot body movement, reduces wearily. The LDC controller may realize the stepless change.
The compact body design, unifies the rear wheel drive to change, causes can also operate in the narrow space freely.
Three set of independent brake ways do not change with the snapping back hydraulic pressure unify, cause the steering control to be more precise.

Model

TF10-30

TF15-30

TF20-30

TF25-30

Load capacityKg

1000

1500

2000

2500

Load centermm

500

500

500

500

Lifting heightmm

3000

3000

3000

3000

Lifting speed(Load)mm/s

285

255

240

220

Driving speedkm/h

8.5

7.5

9.4

9

Forwarding lengthmm

560

560

680

680

Gradeability%

≤10

≤10

≤10

≤10

Fork tilt°

3/5

3/5

3/5

3/5

Turning radiusmm

1610

1610

1965

1965

Overall length(Outstretch)mm

2260

2260

2500

2500

Overall widthmm

1090

1090

1250

1250

Overhead guard heightmm

2280

2280

2280

2280

Mast height

2100

2100

2100

2100

Max lift mast height

3900

3900

3950

3950

Wheelbasemm

1350

1350

1700

1700

Adjust width of forkmm

200-740

250-740

250-812

250-820

Fork sizemm

1070×100×35

1070×100×35

1070×125×40

1070×125×40

Total weightKg

2000

2300

3000

3000

Front wheelmm

267×114

267×114

267×114

267×114

Driving wheelmm

343×114

343×114

343×114

343×114

Balance wheelmm

180×76

180×76

180×76

180×76

Driving motorKW

4

4

5

5

Lifting motorKW

6.3

6.3

7.5

7.5

Battery

48/300

48/300

48/400

48/400

ChargerA

45

45

60

60
