Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
GP
Model Number:
ETM10-30
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1.3 Ton Electric Reach Truck Made in ChinaNegotiableMOQ: 1 Set -
1ton Electric Reach Truck for WarehouseNegotiableMOQ: 1 Set
-
Hot Sale!!! 1.0Ton Electric Reach TruckNegotiableMOQ: 1 Unit
-
Narrow Aisle Reach TruckNegotiableMOQ: 1 Piece
-
Pallet Lift Truck /hydraulic Pallet Truck/ PalletNegotiableMOQ: 1 Unit
Condition
New
Brand Name
GP
Model Number
ETM10-30
Type
Powered Pallet Truck
Power Souce
Other
Rated Loading Capacity
1000KG-2000KG
Max. Lifting Height
8.6m
Min. Lifting Height
3m
Certification
ISO&CE
After-sales Service Provided
Overseas service center available
1) Clear view fixed mast
2) Diagnostics,via a CAN bus connection, enable rapid servicing and maximum uptime
3) Maximum residual capacities at high lift
4) Large capacity Lifting Motor
5) Safety design, reach ISO & CE
2) Diagnostics,via a CAN bus connection, enable rapid servicing and maximum uptime
3) Maximum residual capacities at high lift
4) Large capacity Lifting Motor
5) Safety design, reach ISO & CE
| Electric Reach Truck | Model | |||||||
| Item | Specification | Unit | ETM10-30 | ETM13-30 | ETM15-30 | ETM18-30 | ETM20-30 | |
| 1 | Characteristics | Power | Battery | |||||
| 2 | Operation | Stand-on | Stand-on | Stand-on | Stand-on | Stand-on | ||
| 3 | Rated load capacity | Q(kg) | 1000 | 1300 | 1500 | 1800 | 2000 | |
| 4 | Rated lift height | h3(mm) | 3000 | |||||
| 5 | Load centre | C(mm) | 500 | |||||
| 6 | Fork carriage tilt (Forward/Backward) | α/β(Deg) | 3°/5° | |||||
| 7 | Travel speed (Laden/Unladed) | km/h | 8.0/8.5 | 8/8.5 | 8.8/9.3 | 8.5/9.3 | 9.1/9.0 | |
| 8 | Lifting speed(Laden) | mm/s | 175 | 175 | 240 | 230 | 220 | |
| 9 | Max. gradeability(Laden) | % | >12 | >12 | >12 | >12 | >10 | |
| 10 | Min. turning radius | Wa(mm) | 1420 | 1620 | 1725 | 1735 | 1775 | |
| 11 | Reach distance | X(mm) | 520 | 720 | 600 | 600 | 645 | |
| 12 | Wheelbase | Y(mm) | 1160 | 1360 | 1470 | 1470 | 1520 | |
| 13 | Service brake | Elec | Elec | Elec | Elec | Elec | ||
| 14 | Dimensions | Overall width | l1(mm) | 2115 | 2125 | 2340 | 2350 | 2350 |
| 15 | Main body length | l2(mm) | 1045 | 1055 | 1270 | 1280 | 1280 | |
| 16 | Overall width | b1(mm) | 1045 | 1045 | 1200 | 1216 | 1216 | |
| 17 | Height of mast, lowered | h1(mm) | 2080 | 2080 | 2085 | 2085 | 2085 | |
| 18 | Free lift height | h2(mm) | 330 | |||||
| 19 | Height of mast, extended | h4(mm) | 3915 | 3915 | 4000 | 4000 | 4000 | |
| 20 | Height of overhead guard | h5(mm) | 2210 | 2210 | 2260 | 2260 | 2260 | |
| 21 | Fork dimensions(TxWxL) | mm | 35x100x1070 | 35x100x1070 | 35x122x1070 | 40x122x1070 | 40x122x1070 | |
| 22 | Min. ground clearance | h6(mm) | 80 | |||||
| 23 | Aisle width with pallet (1200x1200) | Ast1(mm) | 2660 | 2710 | 2910 | 2920 | 2920 | |
| 24 | Aisle width with pallet (1000x1000) | Ast2(mm) | 2440 | 2495 | 2690 | 2700 | 2700 | |
| 25 | Weight | Service weight | kg | 2050 | 2150 | 2670 | 2700 | 2725 |
| 26 | Motor | Driven motor | Kw | 2.2 | 2.2 | 4.5 | 4.5 | 4.5 |
| 27 | Lift motor | Kw | 3.5 | 3.5 | 9.2 | 9.2 | 9.2 | |
| 28 | Battery: Voltage/capacity (5h)standard (option) | (V/Ah) | 48/210 *48/225 | 48/210 *48/225 | 48/420 *48/500 | 48/420 *48/500 | 48/420 *48/500 | |
| 29 | Wheel | Tyres | Polyurethane tyre | |||||
| 30 | Size of front tyre | mm | Φ250x70 | Φ250x70 | Φ250x120 | Φ250x120 | Φ250x120 | |
| 31 | Size of rear tyre | mm | Φ381x130 | |||||
| 32 | Size of balancing tyre | mm | Φ178x75 | |||||
| 33 | Track width(front) | mm | 975 | 975 | 1070 | 1070 | 1070 | |
| 34 | Track width(rear) | mm | 490 | 490 | 580 | 580 | 580 | |
| 35 | Turning system | Hydraulic | ||||||
| 36 | Speed control system | ZAPI / Curtis | ||||||
