Cheap Price Electric Forklift Truck CPCD30

Evangel Industrial (Shanghai) Co., Ltd.

US$ 11,000 - 12,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

YTO

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name YTO

Model Number CPCD30

Type Powered Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 3 Ton

Max. Lifting Height 3995mm*2050mm*2550mm

Min. Lifting Height 120mm

Fork Length 1120mm

Fork Width 150mm

Overall Dimensions 3995mm*2050mm*2550mm

Certification ISO;CE

After-sales Service Provided Engineers available to service machinery overseas

Cheap Price Electric forklift truck CPCD30

Specification

Speciality parameter	Model					CPCD30
	Model					CPCD30
	Power type					Diesel
	Rated capacity				kg	3000
	Load center			d	mm	500
	Lift height			h2	mm	3000
	Mast tilt angle (forward/backward)			α/β	Deg	6/12
	Front overhang			L3	mm	685
	Wheel-base			L4	mm	2600
	Tread(front/rear)			b4/b5	mm	1535/1720
Performance parameter	Travel brake					Hydraulic-Foot pedal
	Parking brake					Mechanical-Hand level
	Lift speed(with/without load)				mm/s	320/340
	Lower speed (with/without load)				mm/s	with load300
	Travel speed (with/without load)				km/h	21/24
	Max. gradeability (with load)				%	20
	Max. Towing (with/without load)				kN	43/33
	Weight Distribution with load(pront/rear)					17590/1620
	Weight Distribution without load(pront/rear)					5380/5830
Power, transmission and others	Engine	Model				LR6B5-22
		Manufacturer				YTO
		Rated power			kw	88.2/2200
		Max.roration				440/1600
		Dispilacement				7.42
	Battery	Voltage			V	24
	Battery	Capacity			Ah	2×100
	Gearbox	Transmission type				Hydraulic
	Gearbox	Gears,speed (front/rear)				Ⅱ/Ⅱ
	Tire	type				Pneumatic tyre
		Model	Pront			8.25-20-14PR
		Model	Rear			8.25-20-14PR
Other	Self.weight				kg	11210
	Free lift height			h4	mm	165
	Fork	Thickness×Width×Length		c×b×a	mm	75×175×1220
	Overall dimensions	Overall length(without forks)		L2	mm	3995
		Overall width		b1	mm	2050
		Overall height	Extended height(mast)	h1	mm	4180
			Lower height(mast)	h3	mm	2695
			Overhead guard	h7	mm	2550
	Min. turning radius			Wa	mm	3670
	Min. under ground clearance	Under mast		m1	mm	245
	Min. under ground clearance	Center of wheel-base		m2	mm	230
