Specifications
HBXG 165hp Track Crawler Bulldozer TY165-21) Operating weight:17800kg
2) Engine Weichai rated 121kw
3) Straight shovel
HBXG 165hp Track Crawler Bulldozer TY165-2
TY165-2 bulldozer is semi-rigid suspended, power shift, hydraulically controlled and track-type. It is applicable for road construction, water and electricity engineering farmland leveling, port building, mining and other engineering conditions.
Main specifications (Standard type: Straight dozer)
Overall dimensions (L× W× H): 5236× 3297× 3160 mm
Operation weight: 17800kg
Flywheel power: 121kW
Max. Drawbar pull: 139.6 kN
(The efficient force depends on weight and ground surface adherence)
Ground pressure (at operating weight): 69.2 KPa
Min. Ground radium: 4.0 m
Min. Ground clearance: 352.5 mm
Grade ability: Straight 30; Side 25
Diesel engine
Model: C6121ZG05A
Type: Water-cooled, single-row, vertical, 4-stroke-cycle, turbo-charged
Number of cylinders-bore× Stroke: 6-120.7× 152.4mm
Total piston displacement: 10.5 L
Rated RPM: 1900 r/min
Rated power: 131 kW
Oil consumption (at rated power output)
Fuel consumption: ≤ 244 g/kW*h
Lube oil consumption: ≤ 0.6 g/kW*h
Max. Torque (≤ 1400r/min): ≥ 790 N*m
Cooling method: Closed circulation water cooling
Starting method: By electric at 24V
