High Quality 40ton Container 9402TP 40ft Flatbed Container Semi Trailer

Name: High Quality 40ton Container 9402TP 40ft Flatbed Container Semi Trailer
Brand: Longdi
SKU: 140714896
Availability: InStock

US$ 200,000 - 1,000,000 MOQ: 1 Set

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Certification:

Shanghai Evangel Industrial Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Certification CE

Size 12500*2500*1560mm

OEM No. 9402TP

Max Payload 40t

Brand Name Longdi

Model Number 9402TP

High Quality 40ton container 9402TP 40ft flatbed container semi trailer

Product Description

Technical Specification of High Quality 40ton container 9402TP 40ft flatbed container semi trailer

Vehicle
Vehicle Name		3 axle flatbed semi-trailer
Vehicle model		9402TP
Loading capacity		40T
Function		220ft or 140ft container
Dimension Parameter
Overall length (mm)	12500
Overall width (mm)	2500
Overall height (mm)	1560
Wheelbase (mm)	6400+1310+1310
Front / rear suspension (mm)	-/2050
Front / rear tread (mm)	-/1840/1840/1840
Weight Parameter
GVW (kg)	40000
Payload weight (kg)	34000
Kerb weight (kg)	6000
Others
Spring leaf No.	-/10/10/10
Tyre type	11.00R20
Tyre No.	12
Suspension	3 axle mechanism suspension
Axle	3* 13T FUWA
Landing gear	28T, two-speed, manual operation
Material of main beam	16Mn
Main beam	Height: 480mm, top flange: 12mm, bottom flange:14mm, middle flange: 6mm
Platform plate	3mm
Kingpin size	2” or 3.5”
Electrical	24V, 7 pin socket
Equipment	Double tyre carrier, one tool box
Painting	High quality painting
Others	8pcs twist lock
