4-12mm Automatic steel wire rebar straightening & cutting machine
- 20 Set / Sets per Month
- TIANJIN
- T/T L/C D/P D/A Credit Card PayPal
-
4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
-
Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
-
Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
-
Heavy Duty Automatic Wide Belt Metal Sand Deburring Machine
-
Metal Plate Deburring and Rust Removal Machine Steel Plate Sand Belt Drawing and Polishing Equipment Flat Polishing Machine
-
Metal Flat Sheet Laser Cutting Parts Deburring Grinding Polishing Machine Manufacturer
Product Details
| Brand Name: | HTK | Model Number: | CY-12 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
4-12mm rebar straightening & cutting machine
Exhibition of rebar straightening & cutting machine
Brief introduction of rebar straightening & cutting machine
| rief description | Rebar straightening & cutting machine is used to straightening galvanized wire or rebar,and then cut it into the needed length.It can do a prepare work for the wire mesh welding machine.So it is widely accepted to the factory who is dealing wire wires and wire mesh.Also widely used in construction area. |
| Advantage &Feature | 1.Different lengths and numbers are remembered by the machine; 2.Hydraulic cut off, high accuracy but low noise; 3.Covering Less Space,convenient to move and install ; 5.Alter number and length without shutting; |
Technical parameter of rebar straightening & cutting machine
| Technical parameter of rebar straightening & cutting machine | |||
| Model | GY4-10 | GY4-12 | GY6-14 |
| Straightening Dimension | Φ4-Φ10mm | Φ4-Φ12mm | Φ6-Φ14mm |
| Wire Traction Speed | 25-30m/min | 45m/min | 55m/min |
| Wire Cut Lengths | 100-2500mm(can add) | 800-9000mm(can add) | 800-8000mm(can add) |
| Cutting Length Error | 0 | ±1mm | ±15mm |
| Wire Straightening Degrees | ±2mm/m | ±2mm/m | ±2mm/m |
| Traction Motor | 7.5KW | 2.2KW-6P | 4KW-6p |
| Straightening Motor | 7.5KW-4P | 11KW-4P | |
| Cutting Motor | 4KW-4P | 4KW/5.5kw-4p | |
| Voltage | 220V/380V/415V/440V,50/60HZ,single or double or three phase | ||
| Whole Weight | 140kg | 1300kg | 2000kg |
| Overall Dimension | 2250x450x1000mm | 2100x800x1100mm | 2700×800×1200mm |
Pre-sales Service
1.Reply you enquiry in 24 hours working hours
2.Experienced staffs answer all your questions about the machine
3.Exclusive and unique solution can be provided to our customer by your well-trained and professional engineer.
After-sales Service
1.Maintenance period: one year
If the buyers need, we can send our technical staff to the buyers’ place to debug the machine and providing the training in 20 days after the machines arrive at the destination port.
2.The debugging fees: free
3.The training fees: USD80-100/day for each technical
4.The numbers of technical persons: most often one technical person per net machine
Hebei HTK Welding Equipment Manufacture Co., Ltd
Formerly Known as Shenzhou City Chaoyi Wire Mesh Equipment Co.,Ltd
Business Type: Direct Factory , Manufacturer
Location: Shezhou,Hebei, China(Mainland)
Year Established: 2005
We have 2 senior engineers,10 senior technicians,more than 100 employees
1.> Our products: welded wire mesh machine, Chain link fence machine, field fence machine
2.> Our supply ability: we have the complete accessories, 10 sets per month.
3.> Our warehouse: We have many spot goods to ensure the needs of customers
4.> Our Main Market: Algeria, India, Thailand, Burma, South Africa, South Asia, Egypt, etc
Why choose us?1.Our factory have produced these machines for 20 years,best production capability,best quality control, Best Service;
2.100% QC inspection Before Shippment;
3.ISO/SGS/3C Listed,competitve price.
