China suppler steel wire straightening and cutting machine for India
Steel wire straightening and cutting machine is mainly used to straighten and cut round steel bar, wire rod, deformed steel bar, re-bar, steel bar etc. Our steel bar straightening and cutting machine can process 4-14mm round steel bar or 4-12mm deformed steel bar. Fully automatic CNC control with high accuracy and working efficiency. It's mainly used in building and construction sites, re-bar processing factory, bridge construction etc.
Quality Control of steel wire straightening and cutting machine:
We always pay more attention to the quality of our machine,Standard quality control system and team are responsible to insure the high quality in every process.We are devoted to producing a more efficiency and safer machines.
Features of steel wire straightening and cutting machine:
1.Different lengths and numbers are remembered by the machine;
2.Hydraulic cut off,high accuracy but low noise;
3.Covering Less Space,convenient to move and install ;
4.Running steadily,easy to maintain,exchange parts are available;
5.Alter number and length without shutting;
6.Number of machines can be operated by one worker at a time.
Applications of steel wire straightening and cutting machine:
Ship Building,Construction Equipment,Transport Equipment,Aerospace Industry,Bridge Building, military industrial,wind power,Structural Steel,Boiler containers,Agriculture Machinery,Chassis electrical cabinets,Elevator manufacturers,Textile Machinery,Environmental protection equipment,etc.
Technical parameters of steel wire straightening and cutting machine:
| Model | Wire diameter(mm) | Straightening range(m) | overall dimension)m) | Weight(kg) | Straightening motor(kw) | Cutting motor(kw) | Straightening speed(m/min) | Mould quantity | Straightening srror(mm) | Easy damage part |
| 1 | 2.0-5.0 | 0.1-6.0 | 1.1*0.45*1.0 | 170 | 1.5 | 0.75 | 30 | 1-3 | +5 | Cutter mould |
| 2 | 3.0-6.0 | 0.1-6.0 | 1.3*0.55*1.1 | 200 | 2.2 | 0.75 | 30 | 1-3 | +5 | Cutter mould |
| 3 | 4.0-8.0 | 0.1-9.0 | 1.3*0.6*1.2 | 350 | 5.5 | 2.2 | 35 | 1-2 | +2 | Cutter mould |
| 4 | 5.0-8.0 | 0.1-9.0 | 1.3*0.6*1.2 | 350 | 5.5 | 2.2 | 45 | +5 | ||
| 5 | 5.0-12 | 0.8-12 | 1.9*0.6*1.4 | 1000 | 11 | 3 | 30-45 | 1-2 | +5 | Blade mould |
| 6 | 6.0-12 | 0.8-12 | 5500 | 22 | 4 | 70/100/130 | 1-2 | ≤+1 | Blade mould | |
Productivity formula(kg)=wire diameter*wire diameter*wire length*0.01234/2
1. Packed in wooden case, or customization.
2. FOB Tianjin or other China main port by sea.
3. FOB Beijing airport or China main airport by air.
1.one year guarantee for whole machine
2.24 hour technical support by e-mail
3.calling or door-to-door service
4.use-friendly English software,user manual and detail Videos/CD
If you like to know more about our re-bar straightening and cutting machine, please feel free to contact me!
