Home > Products > Wire Drawing Machine > Water Tank Used High Carbon Steel Wire Drawing Machine
Water Tank Used High Carbon Steel Wire Drawing Machine
- Tianjin-xiangang
- T/T Credit Card
You May Like
-
High Quality Low Noise Automatic Water Tank Wire Drawing Machine
-
Wire Drawing Machine Price (Water Tank Type)/Steel Wire Making Machine
-
High Quality Good Price Water Tank Copper Wire Drawing Machine
-
Makes Ribs From Wire Rod Cold Rolling Mill,ribbed steel bar making machine
-
Cold Rolling Wire Drawing Screw Thread Line,Rebar/Bar Ribbed Steel Cold Rolling Machine
-
Made In China Two Ribbed Rebar Steel Cold Rolling Machinery
Product Details
| Place of Origin | Hebei, China | Brand Name | CY | |
| Model Number | WDM-0211 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Water Tank Used High Carbon Steel Wire Drawing Machine
Feature of wire drawing machine:
Water tank type wire drawing machine the production of the water tank type wire drawing machine is used in wire-drawing of low, medium and high carbon steel wire, stainless steel wire, prestressed steel wire, alloy steel and so on.
The equipment for steel cord, hose wire, spring steel, tempered steel wire tires, gas protection welding wire, and stainless steel wire.
Main Parameter:
Item | Type 1 | Type 2 |
Max. wire coming | 6.5mm | 3.5mm |
Mini. Wire outing | 3.5mm | 1.4mm |
Unit Motor Power | 90Kw 6class slip ring motor | 55Kw 6class slip ring motor |
Total weight | 6T | 3T |
Speed | 5m/second | 5m/second |
Total compression ratio | 80% | 75% |
Average compression ratio | 15% | 15% |
Item | Type 3 | Type 4 |
Max. wire coming | 4.0mm | 2.0mm |
Mini. Wire outing | 1.4-1.8mm | 0.5-0.7mm |
Motor power | 39KW | 13.2KW |
Total weight | 2T | 700kg |
Out put | 5-7tons/24hours | 0.8-1.2tons/24hours |
Main Featrues
1.Precise design, easy operation.
2.High speed and stability fitting your goal of efficiency.
3.Made from high quality material, undergoing high abrasion-resistance and low deformation heat treatment process, the machine is endurable with long time preciseness.
4.The forced feed lubricator guarantees oil-film lubrication of the rubbing parts and ensures the lasting use of the machine.
wire drawing machines can be ordered according customer's request
we also produce others machine,the following is our others machines:
welded wire mesh machine
barbed wire machine
chain link fence making machine
nail making machine
wire drawing machine
grassland fence making machine
expanded metal mesh machine
shuttless weaving mesh machine
pvc wire coating machine
roof and wall steel panel roll forming machine
if you have any question,please contact with me as soon as possible.and welcome to visit our factory
contactor:Lily Zhai
skype:htkmachine
whatsapp:0086 13463185792
wechat: lilyzhai66
QQ :763185887
