RG6/RG11/RG59/RG58 Competitive Coaxial Cable Price

Specifications

RG6/RG11/RG59/RG58 Competitive Coaxial Cable Price
1.High quality
2.Favorable price
3.Attractive design
4.OEM and ODM servic

RG6/RG11/RG59/RG58 Competitive Coaxial Cable Price



*PE Sheath
*Shield:AL Foil+ Al Braiding+Al Foil
*Coverage:40%~95% AL wire
*Jacket:PVC/PE



Usage:



Using in CCTV Camera and applicableto video filed,communication system abd signal controlling system,video monitor  cirsuity ,broadcast signal  control ,public TV antenna,circuit TV monitor system camera .





basic  Construction





type	Conductor (No./mm)	Braid shield (mm)	Material	Reference diameter (mm)	impendence ohm
RG-6/U	1/0.8 BC/CCS/TC	32*0.12	Al-mg/cu	6.8	75
		48*0.12
		64*0.12
	1/1.02 BC/CCS/TC	80*0.12		7.0	75
		96*0.12
		112*0.12
		128*0.12
RG59/U	1/0.64 BC/CCS/TC	32*0.12	Al-mg/cu	6.0	75
		48*0.12
		64*0.12
	1/0.81 BC/CCS/TC	80*0.12		6.0	75
		96*0.12
		112*0.12
RG-8/U	7/0.72 BC/CCS/TC	80*0.16	Al-mg/cu	10.3	52
		112*0.16
		160*0.16
RG11/U	1/1.63 BC/CCS/TC	64*0.12	Al-mg/cu	10.3	75
		128*0.12
		144*0.12
RG58/U	1/0.81 BC/CCS/TC	32*0.12	Al-mg/cu	5.0	50
		64*0.12
RG-58A/U	19/0.18 BC/CCS/TC	80*0.12	Al-mg/cu	5.0	50
		112*0.12
RG-213/U	7/0.75 BC/CCS/TC	80*0.12	Al-mg/cu	10.3	50
		96*0.15
		128*0.16
3C-2V	1/0.5 BC/CCS/TC	64*0.12	Al-mg/cu	5.8	75
		96*0.12
		112*0.12



















  Packing:

1) Packing lengths: 100m/roll, 200m/roll, 300m/roll, 100 yards/roll,
    200 yards/roll, 300yard/roll

2) Inner packing: wooden drum, plastic drum, paper drum

3) Outer packing: carton box, pull out box

4) Other packing available according to client's request



Why choose us



1.High quality

2.Favorable price

3.Great variety of products

4.Attractive design

5.Environment friendly technology
