Portable Ultrasonic Thickness Meter Gauge With Optional Probes

Portable Ultrasonic Thickness Meter Gauge With Optional Probes photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
TM-8810
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Model Number TM-8810

Specifications

Digital Ultrasonic Thickness Meter Gauge with Optional Probes and Measuring range metric: 1.2-200mm / imperial: 0.06-8inch.

Application:
Used for measuring thickness and corrosion of pressure vessels,chemical equipment,boilers,oil storage tanks,etc.in industries of petroleum,shipbuilding,power station,and machine manufacturing.





Specifications:

  • Measuring range (metric/imperial):  1.2-200mm,0.06-8inch
  • Operating principle:  ULTROSONIC
  • Materials measured:  only 11 types of materials, including steel, cast iron, aluminum, red copper, brass, zinc, quartz glass, polyethylene, PVC, gray cast iron, nodular cast iron
  • Lower limit steel pipes:  15x2.0mm,  20x3.0mm determined by the transducer
  • Calibration block:  included
  • Resolution:  0.1mm
  • Accuracy:  ±(0.5%n+0.1)
  • Power supply: 4x1.5vAA(UM-3) battery
  • Battery indicator: low battery indicator
  • Operating conditions:  0-+45°C(32°F-104°F),≤90%RH
  • Dimensions:  160 x 68 x 32mm
  • weight:  208g(not including battery)



Set Includes:

  • 1 x Ultrasonic Thickness Gauge (main unit)
  • 1 x Operating Manual



Optional Accessories:(not included in set)

Please inform us if you want any of the following optional items to be included in your order

  • 6M 6mm thin Material probe:
    • Measuring range(steel): 1.0 50.0mm
    • Operating temperature: -10~+60°C
  • 5M 12high temperature probe:
    • Measuring range(steel): 1.0~225.0mm(normal temperature)
    • Measuring range(steel): 4.0~100.0mm (high temperature)
    • Operating temperature: -10~+300°C
