Model Number
DT-2350PE
Specifications
Digital AC Powered Stroboscope Analyzer w/ measuring range 50-2,000 FPM, Specially designed for Printing And Textile Industry.An essential tool specially designed for printing and textile industry measuring the rotational speed of a rotating object and to inspect the defect on its surface without the need to adhere any mark to reflect the light, and thereby without the need to halt the object from its rotation. Capable to provide image of single, two or multiple stillness for the vibration object, rapidly rolling object or a periodic motion object, and can also use to observe the movement tracks. It uses xenon lamp which has a very bright illumination and allows room light operation at long distance and emits an adjustable flash rate.
Features:
- Provides image of single stillness, two stillness or multiple stillness for the vibration object, rapidly rolling object or a periodic motion object, and can also observe the movement tracks
- Can measure the rotational speed of a rotating object and to inspect the defect on its surface without the need to stop the machine and to adhere any mark to reflect the light and without the need to contact the object
- Offers wide measuring range of 50 to 2,000 FPM with high resolution
- Can be externally triggered or it can trigger external equipment
- Equipped with Flash timer that helps in conservation of the flash tube
- 110V or 220V with Power Plug of you choice (US, UK, AU and EUR are available)
- Allows external triggering device to automatically synchronize with the equipment
- Features instant results that's clearly & legibly shown on an easy-to-read LCD screen and exact reading with no guessing or errors
Specifications:
- Measurement Range: 50 ~ 2,000 FPM
- Designed for Printing And Textile Industry
- Display: 5 digits, 10mm (0.4") LCD
- Parameters Measured: Flashes per Minute (FPM)
- Resolution:
- 0.1 FPM( Less 1000 FPM)
- 1 FPM(Over 1000 FPM)
- Accuracy: ±(0.05%n + 1d)
- Sampling Time: 0.3 second
- Flash Adjust: Coarse adjustment, fine adjustment , ×2 and ÷2 for fast check
- High & Low Range: Manual Conversion (Flashing light is much brighter at low range than at high range)
- Flash tube type: Xenon lamp
- Flash tube life : 100 Million
- Temperature: 0~40°C
- Triggering Mode: Interior/Exterior
- Humidity: Less than 85%RH
Set Includes:
- 1 x Digital Handheld Stroboscope
- 1 pc FREE Spare Flashing Tube Bulb
- 1 pc Spectroscope with power cable
- 1 pc Operating Manual
- 1 pc Protective Carrying Case with contoured rubber compartments
