-196 °C, 5 Minutes quick freezing, the future of frozen food.
The best way to keep the original looks, taste and cells structure
The temperatures of Liquid nitrogen is -196 °C, which is the most ideal refrigeration medium. When it is in contact with food, the nitrogen gas will be able to take the heat of the food away in only few minutes, which maximally preserves the moisture and keep the original taste, looks and cells structure of the food. The ice crystal inside is very tiny and even, which will not break the cells after defrost and the weight loss is only 0.5%. Nitrogen gas is colorless, odorless, nontoxic, which also much safer than Freon and amino.(R22,R717,R404)
Compared to the tradition freezers (R22.R404,R717), it cost less power and far more efficient. The dimension and capacity of the freezers can be customized.
We are so proud to say that we are the leading manufacturer of all kinds of liquid nitrogen freezers, our aim is to make you always one step ahead.
2. Technical parameters:
The main body was made by food grade AISI 304 stainless steel. BASF insulation layer keeps excellent thermal isolation performance. Special design of door seal with automatic heating system, ensure the door opened freely.Adopting HACCP health safety concept, full stainless steel internal structure and Net belt design fully considered for cleaning and maintenance. Easy to operate, PLC+ touch screen control, the temperature and freezing rate can be set as per your requirement.
Brand name |
Cryogenic |
Place of origin |
Beijing, China |
description |
tunnel quick freezer |
Material |
Stainless steel AISI304 |
Dimension |
9600mm * 1800mm * 1800mm |
Convoyer |
Stainless steel mesh belt |
Power |
7.44kw |
The lowest temperature |
-190°C |
Cooling rate |
1-50°C/min, can be set arbitrarily |
Freezing capacity |
1000kg/hour |
Voltage |
380V or 220V (optional) |
Interface |
English |
| Control | PLC+Touch screen control |
| Freezing time | 8 minutes freeze the fish, shrimp to -18C°C |
3. Application:
The freezer is used for freezing vegetables ( A variety of vegetables including green peas, corn, green beans, fried or boiled potatoes, carrots or sliced mushrooms, cauliflower, peppers, tomatoes, cabbage and cut into pieces, sheets, strip ), fruits ( Apple slices, pineapple slices, strawberries, blackberries, cherries, Marin fruit, plums, apricots, purple berries, grapes) and meats ( Pork, beef, mutton, fish fillets, fish sticks, shrimp, seafood)
4. Product Advantages:
a. The freezer uses liquid nitrogen refrigerant, green and safe.
b. The lowest temperature: -150°C.
c. The freezing rate is up to 50°C/min
d. Simple operation, PLC+ touch screen control
e. Quick freezing locks the moisture, keeps the original taste and looks.
f. Energy saving, use little power, and needs small space. No compressor unit, free maintenance
5. Company Profile:
Cryogenic (Beijing) Science & Technology Co.,Ltd, was founded in 2008, the pioneer of ultra low temperature liquid nitrogen system in China. Now we have the largest liquid nitrogen freezer workshop in China. We never stop innovation and improvement. which makes us the market leader in the liquid nitrogen freezing system and frozen food machinery industry.
