China Seafood Cryogenic Freezer,Tunnel Blast Freezer

                                                 SSD Series Seafood Cryogenic Freezer

Summary

The SSD series industrial tunnel blast quick freezers adopt stainless steel wire net belt or plastic net belt. According to different varieties, the products to be frozed can be put in the tray or directly on the conveying belt, and the rapidly frozen by the wind blowingfrom the top to the bottom or by the side wind. The quick-freezing machine of this model has the widest process range. It is suitable for various prepared foods(such as bun, dumpling, fish ball, etc.), seafood and especially varieties unsuitable for fluidized freezing. The optional range for freezing time is within 12~100mins.

Application

It has a wide application, is suitalbe for buns, dumplings, fish ball and other products.

Main technical parameters

Output±10%(kg/h): 300

Refrigerating capacity (kw):70

Freezer length (m): 8

Overall dimensions (m):10.4*3*2.5

Power required (kw) :21.2

Input material temperature (°c):+15

Output material temperature (°c): -18

the freezer  temperature (°c): -36±2

Freezing time (min):12-100 continually adjustable

Refrigerant: R717/R22/R404A
