China Seafood Cryogenic Freezer,Tunnel Blast Freezer
- 10 Set / Sets per Month
- Ningbo Or Shanghai Port China
- T/T Credit Card
- Industrial liquid nitrogen tunnel freezer for food store
- Tunnel freezing and flash freezing machine food with nitrogen
- 500KG Per Hour Poultry Meat Cryogenic Conveyor Freezing IQF Liquid Nitrogen Tunnel Fish Blast Freezer
- Fruit Vegetable IQF Quick Freezing Machine
- Spiral Freezer Iqf Freezer IQF SPIRAL FREEZER
- Spiral Freezing Equipment for Meat Fish Poultry Seafood Dumpling Bread Double Drum Spiral Quick Freezer
Product Details
Condition: | New | Type: | Tunnel Freezer | Place of Origin: | Zhejiang, China |
Brand Name: | Sanshon | Model Number: | SSD | Voltage: | 380V/220V optional |
Power(W): | 5.6kw-15.0kw | Dimension(L*W*H): | 7500*2300*2200mm | Weight: | 3 Tons |
Certification: | CE,UL,ISO | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
SSD Series Seafood Cryogenic Freezer
Summary
The SSD series industrial tunnel blast quick freezers adopt stainless steel wire net belt or plastic net belt. According to different varieties, the products to be frozed can be put in the tray or directly on the conveying belt, and the rapidly frozen by the wind blowingfrom the top to the bottom or by the side wind. The quick-freezing machine of this model has the widest process range. It is suitable for various prepared foods(such as bun, dumpling, fish ball, etc.), seafood and especially varieties unsuitable for fluidized freezing. The optional range for freezing time is within 12~100mins.
Application
It has a wide application, is suitalbe for buns, dumplings, fish ball and other products.
Main technical parameters
Output±10%(kg/h): 300
Refrigerating capacity (kw):70
Freezer length (m): 8
Overall dimensions (m):10.4*3*2.5
Power required (kw) :21.2
Input material temperature (°c):+15
Output material temperature (°c): -18
the freezer temperature (°c): -36±2
Freezing time (min):12-100 continually adjustable
Refrigerant: R717/R22/R404A
Models
Model | Dimension (m) | Power required (kw) | Cold load consumption (kw) | Capacity(kg/h) |
SSD-100 | 8.5*2.8*2.5 | 10.3 | 22 | 100 |
SSD-200 | 10.5*2.8*2.7 | 11.0 | 40 | 200 |
SSD-250 | 10.5*3.1*2.7 | 14.2 | 50 | 250 |
SSD-300 | 12.0*3.3*2.7 | 15.4 | 65 | 300 |
SSD-400 | 13.0*3.3*2.7 | 20.2 | 90 | 400 |
SSD-500 | 14.0*3.3*2.7 | 20.6 | 115 | 500 |
Zhejiang Sanshon Machinery Manufacturing Co., Ltd was founded in 1993, located in the most convenient transportation and prosperous economy of Yangtze River delta Shangyu city, Zhejiang. Zhejiang Sanshon Machinery Manufacturing Co., Ltd adjacent to the beauty of the CaoE river, and in less than 5 KM there are three expressways, they are Hangzhou-Ningbo (G92), Changshu-Taizhou (G15w), and 104 national road line , the HangYong high speed railway. Moreover it is less than 100 KM to Hangzhou and Ningbo airport.
It is specialized in manufacturing food processing machinery, which includes fruit & vegetable hot air drying(AD), quick freezing (IQF), vacuum freeze dryer(FD). The company passed ISO9001:2000 quality standard under the efforts of all employees. There are three equipments has been assessed as National New Product. And in 2007, Sanshon was recognized for New and High Technical enterprise in Zhejiang Province.
The company not only in r&d and manufacturing ,but also enjoy the right of import and export. And the machinery from Sanshon has been exported to more than 10 countries, including Vietnam, Thailand, Uzbekistan, Azerbaijan, Iran, Mexico, Venezuela, Peru, Australia, Cyprus, Libya, etc.
Based on more than 20 years’ experience in food process machinery manufacturing, later it established Shaoxing Sanshon Steel Co., Ltd () and Shundi foods Co., Ltd()in Zhejiang and Shanghai. Sanshon now is capable of providing integrated services, including product consultation, design, workshop establishment, equipment manufacturing and installation, training of machine operation in the field of vacuum freeze drying machine (FD), hot air drying (AD) as well as quick frozen (IQF) machines.
Sanshon is well prepared to be a pioneer in the field of dehydration, quick frozen, vacuum freeze drying to contribute to food processing industry!
Term,Conditions
Ordering Information
Payment:
we usually accept T/T,L/C, please send email to negotiate payment term if you can not accept T/T or L/C.
Packing:
iron framework with external plywood and seaworthy package
Please send email for the extra cost of different packing
Delivery Time:
different products will spend different production period: from 30-120 days after 50% advanced payment.
For urgent order, Could be faster, please send email to negotiate
How to make an order?
1,Client make 50% deposit or open LC after receiving our PI
2,Client approve our equipment,
arrange shipment
1,Client effect balance payment before shipment
2.supplier send original documents or telex release the goods
3,quality warranty for 1 year after shipment
