Seal Of Approval Generator

Seal Of Approval Generator thumbnail-1
Seal Of Approval Generator photo-1
US$ 3,500 - 99,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UK imported
Model Number:
GNRP
Contact Supplier Request Quote Chat Now
Shenzhen Genor Power Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name UK imported
Model Number GNRP
Output Type AC Three Phase
Speed 1500rpm or 1800rpm
Frequency 50Hz or 60Hz
Rated Power 20KVA to1250KVA
Rated Voltage 220V/380V, 230V/400V, 240V/415V
Rated Current 29A to 1800A

Specifications

Seal Of Approval Generator
1. Diesel Generator
2.Factory Direct
3.100% Load Testing
4.CE Certification

    Seal Of Approval Generator



1)Generator choose famous brand UK  Diesel Engine as the dynamic force.

2)The engine has the feature of good power performance,safety,low fuel consumption and good reliability.

3)Our generator sets are widely used as prime or standby power supply in building,bank,supermarket,industrial,factory,fieldwork,oil field,highway and so on.

 Seal Of Approval Generator



Genset Model Prime Power Standby Power Engine Fuel Consumption Cylinder No. Displacement Bore X Stroke
KW KVA KW KVA (g/kwh)  (L ) (mm)
GNRP23 16 20 18 23 404D-22 ≤243 4 2.216 84*100
GNRP33 24 30 26 33 1103A-33G ≤210 3 3.3 105*127
GNRP50 36 45 40 50 1103A-33TG1 ≤212 3 3.3 105*127
GNRP65 48 60 52 65 1103A-33TG2 ≤211 3 3.3 105*127
GNRP73 52 65 58 73 1104A-44TG1 ≤207 4 4.4 105*127
GNRP88 64 80 70 88 1104A-44TG2 ≤213 4 4.4 105*127
GNRP103 75 94 82 103 1006TG1A ≤210 6 5.99 100*127
GNRP150 110 138 120 150 1006TAG ≤205 6 5.99 100*127
GNRP165 120 150 132 165 1006TAG2 ≤205 6 5.99 100*127
GNRP225E 165 206 180 225 1306C-E87TAG3 ≤220 6 8.7 117*136
GNRP250E 180 225 200 250 1306C-E87TAG4 ≤219 6 8.7 117*136
GNRP259E 188 235 207 259 1306C-E87TAG5 ≤221 6 8.7 117*136
GNRP275E 200 250 220 275 1306C-E87TAG6 ≤223 6 8.7 117*136
GNRP344E 250 313 275 344 2206C-E13TAG2 ≤201 6 14.6 137*165
GNRP388E 280 350 310 388 2206C-E13TAG2 ≤198 6 14.6 137*165
GNRP450E 320 400 360 450 2206C-E13TAG3 ≤201 6 14.6 137*165
GNRP500E 360 450 400 500 2506C-E15TAG1 ≤216 6 15 137*171
GNRP550E 400 500 440 550 2506C-E15TAG2 ≤211 6 15 137*171
GNRP625E 450 563 500 625 2806A-E18TAG1A ≤196 6 18.13 145*183
GNRP700E 508 635 560 700 2806A-E18TAG2 ≤203 6 18.13 145*183
GNRP800 580 725 640 800 4006-23TAG2A ≤199 6 22.921 160*190
GNRP900 640 800 720 900 4006-23TAG3A ≤200 6 22.921 160*190
GNRP1000 720 900 800 1000 4008-TAG1A ≤206 8 30.561 160*190
GNRP1125 818 1022 900 1125 4008-TAG2A ≤208 8 30.561 160*190
GNRP1375 1000 1250 1100 1375 4012-46TWG2A ≤212 12 45.482 160*190





Engine Features:

Seal Of Approval Generator

1. Genuine Uk  industrial diesel engine

2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection

3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler

4. Machinery or electronic governing

5. Fuel injection pump

6. Electric motor starting system

7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner

8. Low discharge, and low fuel consumption

9. Installed conveniently and maintain easily





Alternator Features:

Seal Of Approval Generator

1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon, Engga

2. Brushless, 4 poles, rotation magnet

3. IP21-23(NEMA1) enclose is standard for all industrial alternators

4. H class insulation system

5. AVR self-regulated, voltage regulation rate: ≤±1%

6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts

7. Wide range of flange adaptors and single bearing disc coupling

8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528

9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof





Control system with ATS :

Seal Of Approval Generator

1.Auto start when power goes out

2.Auto stop when power comes back on

3.Worldwide technical support with programmable software download

4.Full online documentation

5.Trouble shooting symbols to assist owner on concerns with the generator

6.Safety shutdown feature to protect the engine and generator from damage

7.Totally digital with few points of contact to the engine to increase reliability

8.Exercise features and daily start and stop programmable





Standard configuration of pekins:

1. Starting system: DC alternator is used to start engine

2. Short circuit protection: MCCB air switch

3. Cooling system: combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40°C

4. Filter system: oil, fuel and air filte

5. Accessories: exhaust elbow, bellow, muffler

 Seal Of Approval Generator

OEM Certificate



 Seal Of Approval Generator
