Specifications
65kva Electric Generator-UK Engine With Stamford
-Prime Power:65kva
-Reliable quality & factory price
-ISO9001 & CE
65kva Electric Generator With Stamford Alternator
power generator have earned a reputation for ease of service along with low costs of maintenance and repair and all Power part products carry an unequivocal 12-months warranty from date of purchase.
generator Date
|
DIESEL GENERATOR SET |
GenSet Model |
GNRP65 |
Prime power (KW/KVA) |
52/65 |
|
Standby power (KW/KVA) |
57/72 |
|
Rated voltage(V) |
220/380 |
|
Rated current (A) |
93.6 |
|
Frequency(Hz) |
50 |
|
Rated Rotary Speed (RPM) |
1500 |
|
Power factor |
0.8 |
|
Power supply mode |
3 phase,4wire |
|
Starting method |
24 V DC |
|
|
ENGINE |
Diesel Engine |
UK Imported |
Model |
1104A-44TG1 |
|
Engine prime power (KW/KVA) |
59.6/74.5 |
|
Engine standby power(KW/KVA) |
65.6/82 |
|
Cylinder Qty. |
4 |
|
Fuel consumption.(L/ h) |
208 |
|
Bore(mm) *Stroke (mm) |
105*127 |
|
Compression rate |
17.25:1 |
|
Cooling liquid volume (L) |
13 |
|
Displacement(L) |
4.4 |
|
Lubricant capacity (L) |
8 |
|
Cooling method |
Water cooled |
|
Intake method |
Turbocharged |
|
|
ALTERNATOR |
Alternator Features: 1. ENGGA,Stamford, Leroy Somer, Marathon 2. Brushless, 4 poles, rotation magnet 3. IP21-23(NEMA1) enclose is standard for all industrial alternators 4. H class insulation system 5. AVR self-regulated, voltage regulation rate: ≤±1% 6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts 7. Wide range of flange adaptors and single bearing disc coupling 8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528 9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof |
|
Control panel:
1) The generator control panel is manufactured locally by
2) The panel is provided with:
a) Standard engine instrumentation
b) Voltmeter with selector switch
c) Ammeter with selector switch
d) Frequency meter
e) Current transformers
f) Instrument fuses duly wired and erruled
g) Mcb of suitable rating with overload and short circuit protection
h) With AMF control panel or with ATS (automatic transfer system)
i) With EPA certification
Guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, Genor will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material. After expiration, Genor provides cost spare parts maintenance of gensets
