Specifications
52kw/65kva 100 Amp Generator-OEM
-Stamford Alternator
-ComAp controller
-Warranty:12 months
52kw/65kva 100 Amp Generator
1)Generator choose famous brand UK Diesel Engine as the dynamic force.
2)The engine has the feature of good power performance,safety,low fuel consumption and good reliability.
3)Our generator sets are widely used as prime or standby power supply in building,bank,supermarket,industrial,factory,fieldwork,oil field,highway and so on.
| Genset Model | GNRP72 |
| Prime Power(50HZ) | 52KW / 65KVA |
| Standby Power(50HZ) | 57KW /72KVA |
| Frequency/Speed | 50Hz/1500rpm |
| Voltage | 230V/400V |
| Phases | Three phases, four wires |
| Manufacturer | Xiamen AOSIF Engineering Ltd. |
| Engine Data | |
| Manufacturer | UK imported Engines Company Limited |
| Model | 1104A-44TG1 |
| Engine speed | 1500rpm |
| Engine power | |
| Prime power(Gross ) | 59.6 kWm / 79.9 bhp |
| Prime Power (Net) | 58.4 kWm / 78.3 bhp |
| Standby power(Gross) | 65.6 kWm / 88.0 bhp |
| Standby Power(Net) | 64.3 kWm / 86.2 bhp |
| Number of cylinders | 4 |
| Cylinder arrangement | Vertical in-line |
| Cycle | 4 stroke |
| Aspiration | Turbocharged |
| Combustion system | Direct injection |
| Compression ratio | 17.25:1 |
| Bore and Stroke | 105*127 mm |
| Displacment | 4.4 litres |
| Direction of rotation | Anti-clockwise viewed on flywheel |
| Cooling system | Water cooled |
| Total coolant capacity | 13.0 litres |
| Total lubrication system capacity | 8.0 litres |
| Alternator Data | |
| Manufacturer / Model | Leroy-somer Electro-technique (Fuzhou) Company Ltd. |
| Model | LSA43.2 L65 |
| Output power | 56KW |
| AVR model | R250 |
| Number of phase | 3 |
| Power factor (Cos Phi) | 0.8 |
| Altitude | ≤ 1000 m |
| Overspeed | 2250RPM |
| Number of Pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | ±0.5% |
| Sustained short circuit current | 300% (3 IN) : 10s |
| Total harmonics (TGH/THC) | < 4 % |
| Wave form : NEMA = TIF | < 50 |
| Wave form : I.E.C. = THF | < 2% |
| Bearing | single |
| Coupling | Direct |
Control system with ATS :
1.Auto start when power goes out
2.Auto stop when power comes back on
3.Worldwide technical support with programmable software download
4.Full online documentation
5.Trouble shooting symbols to assist owner on concerns with the generator
6.Safety shutdown feature to protect the engine and generator from damage
7.Totally digital with few points of contact to the engine to increase reliability
8.Exercise features and daily start and stop programmable
Standard configuration :
1. Starting system: DC alternator is used to start engine
2. Short circuit protection: MCCB air switch
3. Cooling system: combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40°C
4. Filter system: oil, fuel and air filte
5. Accessories: exhaust elbow, bellow, muffler
