Help CenterCommercial 480v 50HZ With Cummins Engine Diesel Power Generator 45kva
Related Products
-
230V Industrial Power 250kva Diesel Generator PriceUS$ 5,599 - 9,999MOQ: 1 Set -
Soundproof Engine Generator Price List 20kva to 1250kva With Cummins EngineUS$ 3,145 - 94,589MOQ: 1 Set
-
Global Warranty !!! Water Cooled Diesel Engine Generator 250 KvaUS$ 21,169 - 24,969MOQ: 1 Set
-
AC Electric Power 300 Kva Diesel Generator With Cummins EngineUS$ 25,649 - 30,125MOQ: 1 Set
-
50Hz AC Power Diesel Generator 120 Kva With Cummins EngineUS$ 8,565 - 9,195MOQ: 1 Set
Commercial 480v 50HZ with Cummins Engine diesel power generator 45kva
Type:soundproof /open /trailer /water proof
Genset output power range:20kva to 1250kva
Rated voltage:220/380V,230/400V,240/415V,120/240V
Frequency:50/60HZ
Power factor:0.8
Rated speed:1500/1800rpm
output type:AC three phase/single phase
The specification of the engine
Brand |
|
Cooling Method | water cooled |
Rotating speed | 1500/1800rpm |
Governor system | electrical or mechanical governor |
Aspiration mode | natural aspirated or turbocharged |
Starting method | 12/24V DC electric starting |
Stroke | 4 stroke |
The specification of alternator
Brand | Stamford,marathon, leroy somer.ect |
Regulator | AVR automatic voltage regulating |
Excite type | pret or shunt |
Connecting type | 3PH star, 3PH-DELTA |
Steady frequency change | 0-5% |
No load voltage | ≥95%-105 |
Steady voltage | ≤±1 |
Insulation degree | H degree |
Exclosure degree | IP23 |
Control Panel
1. Key switch (manual type) control panel
Shock resist is fitted between control panel and generator set. Loose sheet is also fitted. The equipments of control panel are Meters with Voltmeter,Ammeter,Frequency list,Water thermometer,Oil pressure gauge,Hour meter.
2. Control parts
Start/stop key switch, start button, emergency stop button, voltage regulation
resistance, speed regulation resistance. Voltage phase switch ,Electric current phase selecting switch.
3. Protection setting for engine
For emergency shut down, overfeed, high water temperature, low oil pressure. ATS switch is optional components when some accidents appear, The digital Protector can shut down immediately, giving the battery voltage alarm and DC electrical source alarm. European extremity, steady wiring, and it can easily dismantle and install.
The above generating set fitted with a base fuel tank for more than 8 hours using.
The specification of 220v Geneator :
1. Short circuit protection: MCCB air switch
2. Cooling system: combined cooling water tank fitted to meet the requirement
of radiation at ambient temperature 40°C
3. Connecting type:3PH star, 3PH-DELTA
4. Filter system: oil, fuel and air filter
5. Accessories: exhaust elbow, bellow, muffler
.
Manufacturing Standards
ISO8528; ISO1105; ISO3046; GB/T2820; GB755; BS5000; NEMAMG-22; YD/T502
Engine :
Original stamford alternator and certificate :
Engine Open type Genset :
Silent Type Diesel Genset
