Chinese Shangchai Diesel Engine Generator Set 400kw

Shenzhen Genor Power Equipment Co., Ltd.
Chinese Shangchai Diesel Engine Generator Set 400kw thumbnail-1
Chinese Shangchai Diesel Engine Generator Set 400kw photo-1
US$ 9,565 - 25,695 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
China Shangchai
Model Number:
GNRS
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name China Shangchai
Model Number GNRS
Output Type AC Three Phase
Speed 1500rpm or 1800rpm
Frequency 50Hz or 60Hz
Rated Power 50kva to 500kva
Rated Voltage 220V/380V, 230V/400V, 240V/415V
Rated Current 72A to 720A

   Chinese Shangchai Diesel Engine Generator Set 400kw



1)Shangchai series diesel generator adopts the famous China-made engine Shangchai diesel engine and the world famous generator stamford. It has the advantage of low oil consumption, high reliability, high performance, low price etc has win a good reputation in the China market and overseas. The quality is the same as the famous brand cummins and perkins, but price is more competitive and attracting!
2)This sets are designed for using in towns, fishing ports, high buildings, railways, sites, ships etc as an electric power source or as reserved power for using on emergent case.
3)The main technical data of GF series all meet the national standard of GB/T2820-1997, this item work out specially for the industrial using diesel generator sets.

Chinese Shangchai Diesel Engine Generator Set 400kw



Genset ModelPrime PowerStandby PowerEngineFuel ConsumptionCylinder No.DisplacementBore X Stroke
KWKVAKWKVA(g/kwh) (L )(mm)
GNRS-55405044554135D≤22648135*140
GNRS-69506355694135D-1≤22648135*140
GNRS-88648071884135AD≤22648.6135*150
GNRS-1047594831044135AZD-1≤22148.6135*150
GNRS-12490113991244135AZD≤22148.6135*150
GNRS-1381001251101384135AZD-2≤22148.6135*150
GNRS-1651201501321656135JZD≤221612.9135*140
GNRS-2351501881652356135AZD-1≤221612.9135*150
GNRS-275200250220275G128ZLD≤218612.9135*150
GNRS-344250313275344G128ZLD1≤218625.8135*150
GNRS-38528035030838512V135JZD≤2181225.8135*150
GNRS-413300375330413G128ZLD11≤218626.8135*150
GNRS-44032040035244012V135AZD≤2181226.8135*150
GNRS-48135043838548112V135AZLD≤2161226.8135*150
GNRS-55040050044055012V135BZLD≤2161226.9135*150
GNRS-61945056349561912V135BZLD2≤2161226.9135*150
GNRS-68850062555068812V135BZLD1≤2161226.9135*150
GNRS-756550700605756NT271LW53≤2161226.9138*150





Engine Features:



1. Cummins engine 20kw-1000kw

2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection

3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler

4. Machinery or electronic governing

5. Fuel injection pump

6. Electric motor starting system

7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner

8. Low discharge, and low fuel



Alternator Features:



1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon, ENGGA

2. Brushless, 4 poles, rotation magnet

3. IP21-23(NEMA1) enclose is standard for all industrial alternators

4. H class insulation system

5. AVR self-regulated, voltage regulation rate: ≤±1%

6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts

7. Wide range of flange adaptors and single bearing disc coupling

8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528

9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof



Control System:



1 a) Automatic alarm system: the unit has the acousto-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over load and over current
   b) Operation display:
       i) Unit voltage, tri-phase load current and frequency display
       ii) Water temperature, oil pressure display
2 Starting system: DC alternator is used to start engine
3 Short circuit protection: MCCB air switch
4 Cooling system: combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40°C
5 Filter system: oil, fuel and air filter
6 Accessories: exhaust elbow, bellow, muffler





 Chinese Shangchai Diesel Engine Generator Set 400kwChinese Shangchai Diesel Engine Generator Set 400kwChinese Shangchai Diesel Engine Generator Set 400kw
