Help CenterHandheld Barcode Scanner for 2D and 1D
Related Products
Model |
HCT-80609 |
|
The processor |
Cortex A9 Dual-core 1.2 GHZ processor |
|
Memory capacity |
ROM:4G RAM:1G |
|
The operating system |
Android 4.2 |
|
Wireless communications |
GPRS(Optional) |
GPRS, EDGE , 4-band 900/1800,850/1900 |
WCDMA(3G, standard) |
band 850/2100,Cat.8 HSDPA Cat.6 HSUPA |
|
WIFI(standard) |
Conform to the IEEE 802.11b/g |
|
Bluetooth(standard) |
Conform to the Bluetooth 4.0 |
|
Display |
4.3 inch IPS Display, resolution of the 480*800, High definition full perspective, distinct under the sun |
|
Touch screen |
Support multi capacitor touch |
|
Indicator light |
Network indicator light, recharge indicator |
|
audio |
Support the voice broadcast |
|
Micro SD card |
Support 32G MICRO SD card |
|
Data security |
data security protection, in a comSJetely off electricity (remove the battery and the power converter), data will not be lost even completely no power supply(no battery and no external power supply) |
|
|
GPS indicators (standard) |
Channel: 12- channel Receive types: L1, C/A code and carrier phase smoothing Re-capture: < 1s The latest ASIC chip; COAST patented Algorithm; EVEREST multipath suppression technique Error range: < = 10 meters |
|
Navigation map |
Support Careland, Baidu, Google, Amap and other navigation map |
|
The input method |
Full-screen handwriting, half screen handwriting, strokes and pinyin, Numbers, letters, symbols |
|
Physical interface |
High-speed USB2.0 device interface, 3.5 stick Plug-in recharge interface |
|
|
Camera (standard) |
The rear 500M megapixel camera with flash |
|
The flashlight |
Low power consumption LED lights, emergency use |
|
The fingerprint module(Optional) |
Registration time < 3s, compare time < 0.1s, compare time of 0.5s (100 PCS) |
|
False Reject Rate < 0.1%, False Accept Rate < 0.001%, fingerprint capacity: 512 | ||
One Dimensional barcode(SE955/N43XX)(Optional) | ||
Read code system |
Can recognize all kinds of main one-dimensional bar code: Code 39,Code 93,Code 128,Codebar,EAN-13,EAN-8,UPC-A,UPC-E,ITF 14,UCC/EAN-128,ITF 25,Matrix 25,EAN-128,ISBN |
|
Read distance |
0 cm~50 cm |
|
Read rate |
first read rate >= 99%, misread rate <= 0.01%, non-read rate <= 0.01% |
|
Two dimensional barcode(Optional) | ||
Moto-SE4500 |
Hardware decoding, Far decoding speed and misread rate <= 0.01% |
|
Newland-EM4100 |
Hardware decoding, Far decoding speed and misread rate <= 0.01% |
|
RFID(Optional) | ||
|
Ultra high frequency (915MHz) |
2~3 m distance for EPC C1 GEN2 / ISO18000-6C protocol of 900 MHZ tag read operation (associated with tags and antenna) |
|
|
High frequency (13.56MHz) |
0~7 cm range for ISO15693, ISO14443 double protocol 13.56 MHz tags for reading and writing (associated with tags and antenna) |
|
Low frequency |
125 K / 134.2 K animal ear tag |
|
PSAM |
Support two PSAM card |
|
High Frequency (CPU card read) |
Support CPU card read and write, used with PSAM |
|
Active in close communication(Optional Customers need to provide module) | ||
Active 2.45 G |
Distance of more than 200m, 200 pcs label can be read all at once |
|
433M |
Distance of more than 200m, distance is adjustable |
|
Battery performance | ||
The battery |
4100mah lithium polymer battery, standby time: more than 150 hours, working time: more than 8 hours, ac adapter charging (1A) |
|
The battery standby time |
After full charge, shut off wireless communication and standby for 360 hours, can run normally |
|
Battery charging time |
Charging time < 4.5 hours |
|
Work time after charging |
More than 8 hours (one charge) |
|
The work environment | ||
Operating temperature |
-20℃~50℃ |
|
Storage temperature |
-20℃~70℃ |
|
Relative humidity |
10%~90%RH, no condensation |
|
Protection grade |
IP65 |
|
Physical parameters | ||
The total weight |
Less than 300g (including battery, charger are not included) |
|
The fuselage size |
148 (length) * 77.5 (width) * 27 (thick) ± 2 mm |
|
The attachment | ||
Standard |
1of lithium battery, 1of charger, 1of USB data line |
|
Configuration model selection are as follows):
HCT-80609 |
Android4.2+3G+WIFI+GPS+bluetooth +camera |
HCT-80609-1 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +HF(13.56M: 14443+15693) |
HCT-80609-2 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +1D(Honeywell scanning head) |
HCT-80609-3 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +2 d scanning(Symbol SE4500) |
HCT-80609-4 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera + UHF(900M) |
HCT-80609-5 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +fingerprint |
HCT-80609-6 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +2.4G |
HCT-80609-7 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +433M |
HCT-80609-8 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +PSAM |
HCT-80609-9 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera + 125K/134.2 |
Example is a single type of digital combination is OK
HCT-80609-12 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +1D+HF |
HCT-80609-13 |
Android4.2+3G+WIFI+GPS+ bluetooth +camera +2D+HF |
