Introduction:
GD-12DBI antenna is a kind of UHF identification antenna, widely used for Marathon Racing and Timing system, or some Logistics or Warehouse system.
When the antenna is connected RFID reader, it can supply a robust solution to today popular item monitoring,enhance business intelligence and customer experience.
User will benefit from fast, hassle-free installation and deployment with the speedway
Specification
Model |
GD-12DBI |
Frequency |
860-960MHz |
Gain |
12dBi |
Polarization Type |
Circular Polarization |
VSWR |
≤1.7 |
Front-to-back Ratio |
≥20dB |
H side Beam Width |
horizontal plane is a width of unexpected turn of 38° |
E side Beam Width |
Vertical plane is a width of unexpected turn of 40° |
Manpower |
20w |
Input Impaction |
50Ω |
Lightning Protection |
DC Ground |
Connector Type |
SMA connector |
Dimensions |
1260*820*20 (mm) or 1260*500*20(mm) optional |
Operating temperature |
-20°C/+65°C |
Weight |
10KG |
Package size |
129*87*8.5cm |
If 4antennas in one package, then package size is 132*87*38cm
