UHF Handheld Reader

CUP

SUMSANG ARM920T@400MHZ

Operation System

Windows CE5.0

Memory

64Mb/128Mb

Flash memory

256Mb

Screen

2.8 inch TFT true color with 240 * 320 resolution  Handwritten touch screen

Barcode Scanning

Support the one-dimensional / two-dimensional laser bar code scan engine

RFID

865-868MHZ or 902-928MHZ, meanwhile can customize other frequency

Standard

Support EPC C1 GEN2/

Reading Range

100-200cm depend on working environment and tag size

Wireless

WIFI is standard , GPRS/Bluetooth are optional

Data Backup

Double backup of SD card and FLASH

Secondary development

MS-EVC4.0 and above, or MS-VS2005

Interface

SIM card, SD card, USB

Protection class

IP54

Drop resistance

1.5 m free fall

Operation temperature

 0 °C to  -50 °C

Storage

-20 °C to  -70 °C

Dimension

ISO 11784/ 85

Storage temperature

-55°C to +100°C

Operating temperature

-40°C to 85 °C
