Help CenterVHF/UHF High Speed Data Radio 475MHz,20W
Related Products
Specifications
1.RF data rate:150Kbps2.Frequency:470-505MHz
3.Modulation:GFSK
4.Weight:900g
5:Size:160*115*45mm
VHF/UHF High Speed Data Radio FC-218
Product Description
FC-218 is RFIC based data radio with RF data rate as high as 150Kbps with fast startup time, which is much suitable for real-time applications. It can easily implement point to point or point to multi-point long-distance data communication.
Applications
Electric power load monitoring, distribution network automation, reactive power compensation
Industrial telemetry & wireless remote control
Earthquake, weather, environmental protection and urban lighting control
Vehicle tracking and asset tracking systems
Water monitoring, waste water management and irrigation control
Gas and oil flow monitoring
Railway, oil field, army automation system
Surveying DGPS/RTK wireless data link
Aerial defense and fire alarm system
Highway automatic billing without parking
Technical specification
Work Frequency |
470-505Mhz, Customize for other band |
RF output power |
15W(default), Max 20W |
Modulation |
GFSK |
Power supply |
12-16V DC |
Sensitivity |
Better than -100dBm @BER=10E-3 |
TX current |
3-4A |
RX current |
<45mA |
RF data rate |
150Kbps |
Port type |
RS-232 |
Port data rate |
9600/19200/38400/57600/115200bps(Set by user) |
TX start time |
<1ms |
TX spurious rejection |
>65dB |
Operate Temperature |
-20°C-- 60°C |
Humidity |
10%-95% RH |
Dimension |
160mm×115mm×45mm |
Weight |
900g |
Send Inquiry to This Supplier
