FC-302 is a synthesized 5-watt FM transceiver module, which is designed for data transportation and voice communication . For the voice communication, it can support selected preemphasis, squelch and audio amplifier. The radio is PLL (Phase Lock Loop Synthesizer ) /microprocessor controlled with optional FSK, GMSK or 4FSK modem board. The application of two-point modulation with good lowfrequency response in the radio also makes it a competitive choice for 1200-19200bps rate data application.Compact dimension and wide range DC support make it flexible to use.
Key features
Programmable 1W~5W Output Power
6.25KHz/12.5KHz/25KHz Channel Spacing
Programmable 16 channels
Fast start-up time:5ms
CTCSS/DCS Encode/Decode
Pocsag Modulation Support
Digital SQ programmable via PC
LED Status Indicator
Time out timer
FCC,CE & AS/NZS Certified
Fully PC Programmable
Interface Description
